GeoVision 16CH H.265 5MP Lite / 2MP HD DVR
SKU: 710-XVL1610-000
UA-XVL1610 is a powerful H.264 / H.265 HD DVR with compact size and supports 16-channel analog camera and 4-channel IP camera inputs, totaling a connection of up to 20 channels. It converts analog signals into high-resolution digitized images up to 5 megapixels. Featuring 4-in-1 video output, UA-XVL1610 supports TVI/AHD/CVI/CVBS connection.
With its Web Client on the web browser, users can access several functions, including Live View, Change Stream, Manual Alarm, Divide Screen, and more. It is also able to trigger Tampering Alarm alerts when cameras are tampered with, which can prevent criminal activities.
With its Web Client on the web browser, users can access several functions, including Live View, Change Stream, Manual Alarm, Divide Screen, and more. It is also able to trigger Tampering Alarm alerts when cameras are tampered with, which can prevent criminal activities.
- Support H.265 / H.264 video formats
- 16-ch TVI / AHD / CVI / CVBS video input
- 4-ch IP camera input
- Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K (3840 x 2160) resolution
- HDMI and VGA simultaneous output
- 1 SATA HDD up to 8 TB
- 4 alarms inputs and 1 alarm output
- Support P2P function for GV-Eye app
- Support ONVIF cameras
Call for Availability
Regular price
$245.19
Sale price
$349
On Sale
Shipping calculated at checkout
UA-XVL1610 is a powerful H.264 / H.265 HD DVR with compact size and supports 16-channel analog camera and 4-channel IP camera inputs, totaling a connection of up to 20 channels. It converts analog signals into high-resolution digitized images up to 5 megapixels. Featuring 4-in-1 video output, UA-XVL1610 supports TVI/AHD/CVI/CVBS connection.
With its Web Client on the web browser, users can access several functions, including Live View, Change Stream, Manual Alarm, Divide Screen, and more. It is also able to trigger Tampering Alarm alerts when cameras are tampered with, which can prevent criminal activities.
With its Web Client on the web browser, users can access several functions, including Live View, Change Stream, Manual Alarm, Divide Screen, and more. It is also able to trigger Tampering Alarm alerts when cameras are tampered with, which can prevent criminal activities.
- Support H.265 / H.264 video formats
- 16-ch TVI / AHD / CVI / CVBS video input
- 4-ch IP camera input
- Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K (3840 x 2160) resolution
- HDMI and VGA simultaneous output
- 1 SATA HDD up to 8 TB
- 4 alarms inputs and 1 alarm output
- Support P2P function for GV-Eye app
- Support ONVIF cameras
Composite Video In:
Yes
Connectivity Technology:
Wired
Country of Origin:
China
DVR Weight:
2.65 lb
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet:
Yes
HDMI:
Yes
HD Recording:
Yes
Manufacturer:
GeoVision, Inc
Manufacturer Website Address:
http://www.geovision.com.tw
Maximum Frame Rate:
30 fps
Maximum Resolution:
5MP
Number of VGA Out:
1
Package Contents:
- 16CH H.265 5MP Lite / 2MP HD DVR
- 3.5" HDD Screw Kit
- 2.5" HDD Screw Kit
- USB Mouse
- Power Adapter (DC 12V, 2A, 24W)
- Download Guide
Power Consumption:
13.80 W
Product Model:
UA-XVL1610
Product Type:
Video Surveillance Station
Remote Management:
Yes
System Components:
Digital Video Recorder
Total Number of Audio In Ports:
4
Total Number of Audio Out Ports:
1
Total Number of Channels:
16
USB:
Yes
Video Formats:
H.264,H.265
Video Signal Format:
PAL,NTSC
