Synology DiskStation DS224+ SAN/NAS Storage System

SKU: DS224+

DiskStationDS224+ | Compact data storage for edge deployments Consolidate and safeguard

Protect all your data with integrated security features and centralized access.

Manage important data

Share, back up, and access files, photos, surveillance video, and more.

Minimize energy impact

15 watts under full operation keeps operating costs low.

Simply faster

DS224+ is faster at indexing files in Synology Drive and Synology Photos and more capable of running demanding web applications compared to previous-generation systems.

Store, share, and protect

Manage all your documents, images, and other files, back up applications and devices, and protect your property with professional video surveillance.



  • SAN/NAS Storage System is the single answer to all your desired storage needs
  • Can hold 2 HDDs simultaneously
  • Through RAID levels (0, 1, basic, hybrid raid, jbod), RAID provides data reliability, fault tolerance and improves overall performance
  • DDR4 SDRAM memory technology for dependable data storage with maximum usability
  • Experience responsive performance, power, adaptability and fun with Intel Celeron 2 ghz processor
  • Desktop form factor for your convenience and simplicity of usage
  • Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
  • It's diskstation manager operating system offers powerful platform to efficiently run routine applications

Call for Availability

Regular price $380.72

Shipping calculated at checkout

Details

DiskStationDS224+ | Compact data storage for edge deployments Consolidate and safeguard

Protect all your data with integrated security features and centralized access.

Manage important data

Share, back up, and access files, photos, surveillance video, and more.

Minimize energy impact

15 watts under full operation keeps operating costs low.

Simply faster

DS224+ is faster at indexing files in Synology Drive and Synology Photos and more capable of running demanding web applications compared to previous-generation systems.

Store, share, and protect

Manage all your documents, images, and other files, back up applications and devices, and protect your property with professional video surveillance.



  • SAN/NAS Storage System is the single answer to all your desired storage needs
  • Can hold 2 HDDs simultaneously
  • Through RAID levels (0, 1, basic, hybrid raid, jbod), RAID provides data reliability, fault tolerance and improves overall performance
  • DDR4 SDRAM memory technology for dependable data storage with maximum usability
  • Experience responsive performance, power, adaptability and fun with Intel Celeron 2 ghz processor
  • Desktop form factor for your convenience and simplicity of usage
  • Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
  • It's diskstation manager operating system offers powerful platform to efficiently run routine applications
Specifications
Controller Type:
Serial ATA
Drive Interface:
Serial ATA
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Desktop
Manufacturer:
Synology, Inc
Manufacturer Website Address:
http://www.synology.com
Maximum Power Supply Wattage:
60 W
Memory Technology:
DDR4 SDRAM
Network (RJ-45):
Yes
Number of 2.5"/3.5" Bays:
2
Number of Hard Drives Installed:
0
Number of Hard Drives Supported:
2
Number of Network (RJ-45) Ports:
2
Number of Processors Installed:
1
Number of Solid State Drive Installed:
0
Number of Solid State Drive Supported:
2
Number of Total Expansion Bays:
2
Number of USB 3.2 Gen 1 Ports:
2
Operating System:
DiskStation Manager
Packaged Quantity:
1
Processor Core:
Quad-core (4 Core)
Processor Manufacturer:
Intel
Processor Model:
J4125
Processor Speed:
2 GHz
Processor Type:
Celeron
Product Line:
DiskStation
Product Model:
DS224+
Product Type:
SAN/NAS Storage System
Protocols:
iSCSI,CIFS,AFP,FTP,NFS,WEBDAV,Kerberos,SMB 1.0,SMB 2.0,SMB 3.0,NFSv3,NFSv4,NFSv4.1,HTTP,HTTPS,SNMP,LDAP,CalDAV
RAID Levels:
0, 1, Basic, Hybrid RAID, JBOD
RAID Supported:
Yes
Standard Memory:
2 GB
Total Number of USB Ports:
2
