Tenda 9-Port 10/100Mbps Desktop Switch With 8-Port PoE
SKU: TEF1109P-8-63W
TEF1109P-8-63W is an 9-Port 10/100Mbps Desktop Switch With 8-Port PoE developed by Tenda. It provides 9 10/100 BASE-TX RJ45 ports. Ports 1-8 support IEEE 802.3at PoE standard with each port providing power of 15.4W, or support IEEE 802.3af PoE+ standard with each port providing power of 30W. The whole device can provide power of up to 58W. By using CAT5 twisted pairs, it can provide power and data transmission to APs, IP cameras, IP phones, and so on. In addition, all the port s support lightning protection of 6kV and long distance data transmission and powering of 250m, which decreases deploy ment difficulty and time thus decreases cost.
Lightning Protection 6kV
The ports and embedded power can provide lightning protection of up to 6kV. It also provides PSE shortcircuiting protection, PoE overloading, power over temperature, over voltage and surge current protection.
Outstanding PoE Power Supply
Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.
250 Meters Transmission
With 8-pin and the professional network extension technology, the transmis- sion distance of power and data can be up to 250 meters, which can work in place of network extender or some optical fiber to expand the network without additional cost.
Lightning Protection 6kV
The ports and embedded power can provide lightning protection of up to 6kV. It also provides PSE shortcircuiting protection, PoE overloading, power over temperature, over voltage and surge current protection.
Outstanding PoE Power Supply
Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.
250 Meters Transmission
With 8-pin and the professional network extension technology, the transmis- sion distance of power and data can be up to 250 meters, which can work in place of network extender or some optical fiber to expand the network without additional cost.
- Ethernet Switch provides dependable and powerful connectivity for maximum usability
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 9 ports
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- The desktop installation makes it ideal for deployments outside the wiring closet
- Fast Ethernet technology gives ideal solution for extending network connections to conference rooms, labs, lobbies and department workgroups
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
Call for Availability
Regular price
$38.83
Sale price
$59.99
On Sale
Shipping calculated at checkout
TEF1109P-8-63W is an 9-Port 10/100Mbps Desktop Switch With 8-Port PoE developed by Tenda. It provides 9 10/100 BASE-TX RJ45 ports. Ports 1-8 support IEEE 802.3at PoE standard with each port providing power of 15.4W, or support IEEE 802.3af PoE+ standard with each port providing power of 30W. The whole device can provide power of up to 58W. By using CAT5 twisted pairs, it can provide power and data transmission to APs, IP cameras, IP phones, and so on. In addition, all the port s support lightning protection of 6kV and long distance data transmission and powering of 250m, which decreases deploy ment difficulty and time thus decreases cost.
Lightning Protection 6kV
The ports and embedded power can provide lightning protection of up to 6kV. It also provides PSE shortcircuiting protection, PoE overloading, power over temperature, over voltage and surge current protection.
Outstanding PoE Power Supply
Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.
250 Meters Transmission
With 8-pin and the professional network extension technology, the transmis- sion distance of power and data can be up to 250 meters, which can work in place of network extender or some optical fiber to expand the network without additional cost.
Lightning Protection 6kV
The ports and embedded power can provide lightning protection of up to 6kV. It also provides PSE shortcircuiting protection, PoE overloading, power over temperature, over voltage and surge current protection.
Outstanding PoE Power Supply
Ports 1-8 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.
250 Meters Transmission
With 8-pin and the professional network extension technology, the transmis- sion distance of power and data can be up to 250 meters, which can work in place of network extender or some optical fiber to expand the network without additional cost.
- Ethernet Switch provides dependable and powerful connectivity for maximum usability
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 9 ports
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- The desktop installation makes it ideal for deployments outside the wiring closet
- Fast Ethernet technology gives ideal solution for extending network connections to conference rooms, labs, lobbies and department workgroups
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
Ethernet Technology:
Fast Ethernet
Form Factor:
Desktop
Layer Supported:
2
Manufacturer:
Tenda Technology Inc
Manufacturer Website Address:
http://www.tendaus.com
Media Type Supported:
Twisted Pair
Modular:
No
Network Technology:
10/100Base-TX
Packaged Quantity:
1
Port/Expansion Slot Details:
9 x Fast Ethernet Network
Power Source:
Power Supply
Product Model:
TEF1109P-8-63W
Product Type:
Ethernet Switch
Redundant Power Supply Supported:
No
Stack Port:
No
Total Number of Network Ports:
9
Uplink Port:
No
