NVIDIA OSFP Splitter Network Cable
NVIDIA®MCA7J60is an 800Gb/s twin-port OSFP (Octal Small Form-factor Pluggable) to 2x400Gb/s OSFP passive Active Copper Cable (ACC) dual breakout (aka splitter) cable.The ACC uses 8-channels of 100G-PAM4 modulation and has lengths of 4 and 5-meters. It has identical design and internals as the QSFP112 version, only with different connector shells.
The ACC firmware supports both InfiniBand and Ethernet and is automatically enabled depending on the protocol of the switch attached to. The 8-channel, twin-port, OSFP end uses a finned top form-factor for use in Quantum-2 and Spectrum-4 switch cages. The two 400G ends support 4-channels of 100G-PAM4 (400G) use a flat top OSFP for use in ConnectX-7 adaptersusing riding heat sinks on the connector cage. For use in liquid-cooled systems, a twin-port OSFP version is available with a flat top (designated -FLT in the part number).
ACC cables are the second lowest-cost, low-latency, low-power consuming, high-speed links next to passive DACs due to their simplicity of design and minimal components.The "active" term refers to the passive copper cable with an equalizer integrated circuit to extend the length to 4 and 5-meterswhile maintaining low-latency and low-power at 1.5 Watts and 0.6 Watts.
Thin 30AWG is used for 4m lengths and thicker 26AWG for 5m.Each end includes an EEPROM which provides product identification and characteristics to the host system.
Main use is linking an 800Gb/s Quantum-2 switch or Spectrum-4 switch to OSFP-based 400Gb/s ConnectX-7 PCIe network adapter cards.
NVIDIA's cable solutions provide power-efficient connectivity enabling higher port bandwidth, density and configurability at a low cost and reduced power requirement in the data centers. Rigorous cable production testing ensures best out-of-the-box installation experience, performance, and durability.
- For exceptional quality, upright compatibility and reliability use this network cable
- Features OSFP cable type for your convenience and desired usability
- Passive feature for your convenience and ease of usage
- Network Device device supported according to your requirements with maximum productivity
5 in stock
Shipping calculated at checkout
NVIDIA®MCA7J60is an 800Gb/s twin-port OSFP (Octal Small Form-factor Pluggable) to 2x400Gb/s OSFP passive Active Copper Cable (ACC) dual breakout (aka splitter) cable.The ACC uses 8-channels of 100G-PAM4 modulation and has lengths of 4 and 5-meters. It has identical design and internals as the QSFP112 version, only with different connector shells.
The ACC firmware supports both InfiniBand and Ethernet and is automatically enabled depending on the protocol of the switch attached to. The 8-channel, twin-port, OSFP end uses a finned top form-factor for use in Quantum-2 and Spectrum-4 switch cages. The two 400G ends support 4-channels of 100G-PAM4 (400G) use a flat top OSFP for use in ConnectX-7 adaptersusing riding heat sinks on the connector cage. For use in liquid-cooled systems, a twin-port OSFP version is available with a flat top (designated -FLT in the part number).
ACC cables are the second lowest-cost, low-latency, low-power consuming, high-speed links next to passive DACs due to their simplicity of design and minimal components.The "active" term refers to the passive copper cable with an equalizer integrated circuit to extend the length to 4 and 5-meterswhile maintaining low-latency and low-power at 1.5 Watts and 0.6 Watts.
Thin 30AWG is used for 4m lengths and thicker 26AWG for 5m.Each end includes an EEPROM which provides product identification and characteristics to the host system.
Main use is linking an 800Gb/s Quantum-2 switch or Spectrum-4 switch to OSFP-based 400Gb/s ConnectX-7 PCIe network adapter cards.
NVIDIA's cable solutions provide power-efficient connectivity enabling higher port bandwidth, density and configurability at a low cost and reduced power requirement in the data centers. Rigorous cable production testing ensures best out-of-the-box installation experience, performance, and durability.
- For exceptional quality, upright compatibility and reliability use this network cable
- Features OSFP cable type for your convenience and desired usability
- Passive feature for your convenience and ease of usage
- Network Device device supported according to your requirements with maximum productivity
