Mellanox Edgecore AS4610-54P v1 Layer 3 Switch
SKU: 4610-54P-O-AC-F-V1
The Edgecore AS4610 series is a high-performance Gigabit Ethernet Layer 3 switch family featuring 54 ports; 48 10/100/1000BASE-T ports, 4 x 10G SFP+ uplink ports, and 2 x 20G QSFP+ stacking ports (Stacking capability subject to NOS implementations).
The AS4610-54T is ideal as a data center top-of-rack switch or IPMI (Intelligent Platform Management Interface) switch, it includes redundant hot-swappable AC PSUs and port-to-power or power-to-port (AS4610-54T v1 only) airflow.The AS4610-54P v1 fully supports IEEE 802.3at and IEEE 802.3af Power-over-Ethernet (PoE). The AS4610-54P v1 is an ideal for campus networking and able to provide up to 30 Watts of power per port to attached devices (eight ports support UPoE up to 60 W per port), such as VoIP phones, wireless access points, surveillance cameras etc, fully utilizing existing Cat. 5 cable infrastructure.
The AS4610-54T is ideal as a data center top-of-rack switch or IPMI (Intelligent Platform Management Interface) switch, it includes redundant hot-swappable AC PSUs and port-to-power or power-to-port (AS4610-54T v1 only) airflow.The AS4610-54P v1 fully supports IEEE 802.3at and IEEE 802.3af Power-over-Ethernet (PoE). The AS4610-54P v1 is an ideal for campus networking and able to provide up to 30 Watts of power per port to attached devices (eight ports support UPoE up to 60 W per port), such as VoIP phones, wireless access points, surveillance cameras etc, fully utilizing existing Cat. 5 cable infrastructure.
- Compatible with Cumulus ® Linux ® r2.5.4 and later version from Cumulus Networks ® . (AS4610-54T v1 and AS4610-54P v1 only)
- Hot-swappable, load-sharing, redundant AC PSUs.
- Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commerical NOS offerings.
- Energy efficiency: Maximum 99.1 W system power consumption excluding PoE power consumption.
- Full line-rate L2 or L3 forwarding and switching.
- 4 x SFP+ uplink ports, supporting 10 GbE (DAC, 10GBASE-SR/LR/ER/LRM) or 1 GbE (1000BASE-T/SX/LX).
- PoE models ideal for enterprise, hospitality, warehouse applications interconnecting security, camera, WiFi devices.
- 48 x 10/100/1000BASE-T RJ-45 ports.
- 1 GbE connections to server and storage nodes in rack, with 10 GbE uplinks to spine network.
- Cost-effective, bare-metal infrastructure for data center racks.
Call for Availability
Regular price
$4,012.86
Sale price
$5,756.00
On Sale
Shipping calculated at checkout
The Edgecore AS4610 series is a high-performance Gigabit Ethernet Layer 3 switch family featuring 54 ports; 48 10/100/1000BASE-T ports, 4 x 10G SFP+ uplink ports, and 2 x 20G QSFP+ stacking ports (Stacking capability subject to NOS implementations).
The AS4610-54T is ideal as a data center top-of-rack switch or IPMI (Intelligent Platform Management Interface) switch, it includes redundant hot-swappable AC PSUs and port-to-power or power-to-port (AS4610-54T v1 only) airflow.The AS4610-54P v1 fully supports IEEE 802.3at and IEEE 802.3af Power-over-Ethernet (PoE). The AS4610-54P v1 is an ideal for campus networking and able to provide up to 30 Watts of power per port to attached devices (eight ports support UPoE up to 60 W per port), such as VoIP phones, wireless access points, surveillance cameras etc, fully utilizing existing Cat. 5 cable infrastructure.
The AS4610-54T is ideal as a data center top-of-rack switch or IPMI (Intelligent Platform Management Interface) switch, it includes redundant hot-swappable AC PSUs and port-to-power or power-to-port (AS4610-54T v1 only) airflow.The AS4610-54P v1 fully supports IEEE 802.3at and IEEE 802.3af Power-over-Ethernet (PoE). The AS4610-54P v1 is an ideal for campus networking and able to provide up to 30 Watts of power per port to attached devices (eight ports support UPoE up to 60 W per port), such as VoIP phones, wireless access points, surveillance cameras etc, fully utilizing existing Cat. 5 cable infrastructure.
- Compatible with Cumulus ® Linux ® r2.5.4 and later version from Cumulus Networks ® . (AS4610-54T v1 and AS4610-54P v1 only)
- Hot-swappable, load-sharing, redundant AC PSUs.
- Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commerical NOS offerings.
- Energy efficiency: Maximum 99.1 W system power consumption excluding PoE power consumption.
- Full line-rate L2 or L3 forwarding and switching.
- 4 x SFP+ uplink ports, supporting 10 GbE (DAC, 10GBASE-SR/LR/ER/LRM) or 1 GbE (1000BASE-T/SX/LX).
- PoE models ideal for enterprise, hospitality, warehouse applications interconnecting security, camera, WiFi devices.
- 48 x 10/100/1000BASE-T RJ-45 ports.
- 1 GbE connections to server and storage nodes in rack, with 10 GbE uplinks to spine network.
- Cost-effective, bare-metal infrastructure for data center racks.
Compatible Rack Unit:
1U
Country of Origin:
Taiwan
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet,10 Gigabit Ethernet,20 Gigabit Ethernet
Expansion Slot Type:
SFP+,QSFP+
Form Factor:
Rack-mountable
Layer Supported:
3
Limited Warranty:
1 Year
Manageable:
Yes
Manufacturer:
NVIDIA Corporation
Manufacturer Website Address:
http://www.nvidia.com
Media Type Supported:
Twisted Pair,Optical Fiber
Modular:
Yes
Network Technology:
10/100/1000Base-T,10GBase-X,20GBase-X
Number of SFP+ Slots:
4
Package Contents:
- Edgecore AS4610-54P v1 Layer 3 Switch
- Redundant Hot-swappable AC PSUs
Port/Expansion Slot Details:
48 x Gigabit Ethernet Network,4 x 10 Gigabit Ethernet Uplink,2 x 20 Gigabit Ethernet Stack
Power Consumption:
117 W
Power Source:
Power Supply
Product Model:
AS4610-54P v1
Product Type:
Layer 3 Switch
Redundant Power Supply Supported:
Yes
Shared SFP Slot:
No
Stack Port:
Yes
TAA Compliant:
Yes
Total Number of Expansion Slots:
6
Total Number of Network Ports:
48
Uplink Port:
Yes
