Kramer 1:2 4K60 4:2:0 Long-Reach HDBaseT DA
VM-2DT is a high-quality, long-reach 4K@60Hz (4:2:0) HDBaseT distributor that takes one long-reach HDBaseT input, equalizes and reclocks the signal and distributes it to two identical HDBaseT outputs. The VM-2DT distributes native long-reach HDBaseT signals with up to 4K video resolution, along with their re-extension over long-reach HDBaseT to feature an integrated extender distributor product.
- High Performance Extender Distributor - High-quality professional 1:2 distribution of native long-reach HDBaseT signals, for deploying mid-way between AV source and multiple remote displays and gaining extra long-reach extension. It is coupled with both sides, input and output, extension of maximum 4K@60Hz (4:2:0) 24bpp video resolution signal to maximum 40m (130ft) long-reach over CAT copper cable, and even further reach for lower HD video resolution. Extender distributor is standard, capable of being connected to any market-available HDBaseT compliant extending products.
- Cables - For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/VM-2DT.
- HDMI Signal Transmission - HDMI 2.0 and HDCP 1.4 compliant signal, supporting deep color, x.v.Color™, lip sync, 7.1 PCM, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D. EDID and CEC (OUT 1 only) signals are passed through from the source to the display.
- I-EDIDPro™ Kramer Intelligent EDID Processing™ - An intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
- LED Indicators - Status indicators for HDBaseT input and output connected signals, and power indicator, for ease of maintenance and troubleshooting.
- Easy Installation - Twisted-pair cables for HDBaseT signals wiring. Compact Mega TOOLS™ fan-less enclosure for over-ceiling mounting, or side-by-side rack mounting.
- Audio - E
- Size - MegaTOOLS® - Mount 2 units side-by-side in a 1U rack space with the optional RK-T2B rack adapter.
- Compliance - HDMI 2.0, HDCP 1.4, HDBaseT 1.0
- Video Resolution - Up to 4K (4:2:0) 24bpp
- Reach - Up to 2 x 40m (130ft) at 4K (4:2:0)
- 1:2 line extender distributor
Call for Availability
Shipping calculated at checkout
VM-2DT is a high-quality, long-reach 4K@60Hz (4:2:0) HDBaseT distributor that takes one long-reach HDBaseT input, equalizes and reclocks the signal and distributes it to two identical HDBaseT outputs. The VM-2DT distributes native long-reach HDBaseT signals with up to 4K video resolution, along with their re-extension over long-reach HDBaseT to feature an integrated extender distributor product.
- High Performance Extender Distributor - High-quality professional 1:2 distribution of native long-reach HDBaseT signals, for deploying mid-way between AV source and multiple remote displays and gaining extra long-reach extension. It is coupled with both sides, input and output, extension of maximum 4K@60Hz (4:2:0) 24bpp video resolution signal to maximum 40m (130ft) long-reach over CAT copper cable, and even further reach for lower HD video resolution. Extender distributor is standard, capable of being connected to any market-available HDBaseT compliant extending products.
- Cables - For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/VM-2DT.
- HDMI Signal Transmission - HDMI 2.0 and HDCP 1.4 compliant signal, supporting deep color, x.v.Color™, lip sync, 7.1 PCM, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D. EDID and CEC (OUT 1 only) signals are passed through from the source to the display.
- I-EDIDPro™ Kramer Intelligent EDID Processing™ - An intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
- LED Indicators - Status indicators for HDBaseT input and output connected signals, and power indicator, for ease of maintenance and troubleshooting.
- Easy Installation - Twisted-pair cables for HDBaseT signals wiring. Compact Mega TOOLS™ fan-less enclosure for over-ceiling mounting, or side-by-side rack mounting.
- Audio - E
- Size - MegaTOOLS® - Mount 2 units side-by-side in a 1U rack space with the optional RK-T2B rack adapter.
- Compliance - HDMI 2.0, HDCP 1.4, HDBaseT 1.0
- Video Resolution - Up to 4K (4:2:0) 24bpp
- Reach - Up to 2 x 40m (130ft) at 4K (4:2:0)
- 1:2 line extender distributor
- 1:2 4K60 4:2:0 Long-Reach HDBaseT DA
- Power Supply
