Eaton Tripp Lite Series SmartPro 1500VA 1500W 208V Line-Interactive Sine Wave UPS - 8 Outlets, Extended Run, Network Card Included, LCD, USB, DB9, 2U Rack/Tower

SKU: SMX1500XLRT2UN
1.5kVA/1.5kW/208V Battery Backup for Distributed IT, Telecom or Enterprise Deployments
This rack-mount line-interactive UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage your valuable IT equipment or destroy data. The SMX1500XLRT2UN is ideal power management for high-end in-rack networking equipment, including servers, VoIP phones, data storage and PoE switches. Unity power factor ensures the most watts possible at each power rating, so you can connect more equipment.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
The field-replaceable, hot-swappable VRLA internal battery modules allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Switchover from line to battery power happens within milliseconds to maintain continuous operation of connected equipment without interruption or rebooting. Extra runtime is available by connecting up to four optional extended battery modules (BP48VRM2U, sold separately).

Pre-Installed LX Platform Network Management Card Allows Remote Access 24/7
The WEBCARDLXE network interface enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. The IP-based Auto Probe feature ensures continuous network uptime by communicating with other network devices, detecting lost connectivity and automatically rebooting IT equipment. Optional EnviroSense2 modules (E2MT, E2MTDO and E2MTHDI, all sold separately) provide a variety of environmental monitoring and control options.

C13 Outlets Protect Your Connected Components
Eight C13 outlets provide connected equipment with pure sine wave AC output and allow you to monitor power consumption down to the outlet group level. Power provided by these outlets is filtered to protect connected equipment against damaging surges and line noise. Four outlets are grouped into two programmable load banks that let you shed non-critical loads to extend runtime for critical loads. Front and rear cooling fans help protect equipment from overheating.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The SMX1500XLRT2UN maintains regulated 208V nominal output during brownouts and overvoltages from 160V to 294V while keeping the battery fully charged and ready to take over in case of power failure.

Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better
This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer.

ENERGY STAR-Certified to Help You Save Money and Protect the Environment
By meeting strict U.S. Department of Energy and U.S. Environmental Protection Agency requirements, this ENERGY STAR 2.0 UPS system provides high operational efficiency to signal a reduction in BTU emissions, save on utility and cooling costs and help protect the environment.

  • Provides complete battery backup and pure sine wave power output for servers, switches and other high-end distributed IT equipment
  • Protects equipment against blackouts, brownouts, transient surges and line noise
  • Keeps equipment running during outages to allow time for file saves and safe shutdown
  • Unity power factor ensures maximum power possible at each power rating
  • Included WEBCARDLXE network interface allows 24/7 remote access and control
  • 2-line front-panel LCD with 10 selectable screens reports detailed UPS and site power info
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.

Call for Availability

Regular price $2,550.45

Shipping calculated at checkout

Details
1.5kVA/1.5kW/208V Battery Backup for Distributed IT, Telecom or Enterprise Deployments
This rack-mount line-interactive UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage your valuable IT equipment or destroy data. The SMX1500XLRT2UN is ideal power management for high-end in-rack networking equipment, including servers, VoIP phones, data storage and PoE switches. Unity power factor ensures the most watts possible at each power rating, so you can connect more equipment.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
The field-replaceable, hot-swappable VRLA internal battery modules allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Switchover from line to battery power happens within milliseconds to maintain continuous operation of connected equipment without interruption or rebooting. Extra runtime is available by connecting up to four optional extended battery modules (BP48VRM2U, sold separately).

Pre-Installed LX Platform Network Management Card Allows Remote Access 24/7
The WEBCARDLXE network interface enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. The IP-based Auto Probe feature ensures continuous network uptime by communicating with other network devices, detecting lost connectivity and automatically rebooting IT equipment. Optional EnviroSense2 modules (E2MT, E2MTDO and E2MTHDI, all sold separately) provide a variety of environmental monitoring and control options.

C13 Outlets Protect Your Connected Components
Eight C13 outlets provide connected equipment with pure sine wave AC output and allow you to monitor power consumption down to the outlet group level. Power provided by these outlets is filtered to protect connected equipment against damaging surges and line noise. Four outlets are grouped into two programmable load banks that let you shed non-critical loads to extend runtime for critical loads. Front and rear cooling fans help protect equipment from overheating.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The SMX1500XLRT2UN maintains regulated 208V nominal output during brownouts and overvoltages from 160V to 294V while keeping the battery fully charged and ready to take over in case of power failure.

Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better
This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer.

ENERGY STAR-Certified to Help You Save Money and Protect the Environment
By meeting strict U.S. Department of Energy and U.S. Environmental Protection Agency requirements, this ENERGY STAR 2.0 UPS system provides high operational efficiency to signal a reduction in BTU emissions, save on utility and cooling costs and help protect the environment.

  • Provides complete battery backup and pure sine wave power output for servers, switches and other high-end distributed IT equipment
  • Protects equipment against blackouts, brownouts, transient surges and line noise
  • Keeps equipment running during outages to allow time for file saves and safe shutdown
  • Unity power factor ensures maximum power possible at each power rating
  • Included WEBCARDLXE network interface allows 24/7 remote access and control
  • 2-line front-panel LCD with 10 selectable screens reports detailed UPS and site power info
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
Specifications
Alarm:
UPS StartUp,Power Failure,Low Battery,Overload,UPS Fault,Remote Shutdown
Application/Usage:
Telecommunication,Network Device,Wiring Closet,Gaming Console,Digital Signage,Retail Building,Casino,Mission Critical Equipment,Server,Hotel/Motel Management,Security System
AVR:
Yes
Backup/Run Time (Full Load):
4.90 Minute
Backup/Run Time (Half Load):
13.60 Minute
Country of Origin:
China
DC System Voltage:
36 V DC
EMI/RFI Noise Filter:
Yes
Energy Saving:
Green Energy-Saving
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Environmental Sensors:
Temperature Sensor,Humidity Sensor
EPO Port:
Yes
Form Factor:
Rack/Tower
Hot Swappable:
Yes
Input Frequency:
50 Hz
Input Voltage:
230 V AC
Limited Warranty:
2 Year
Load Capacity (VA):
1500 VA
Load Capacity (Watt):
1500 W
Manufacturer:
Eaton Corporation
Manufacturer Website Address:
http://www.eaton.com
Maximum Operating Temperature:
104°F (40°C)
Network Management:
SNMP/Telnet/SSH
Output Frequency:
60 Hz
Output Voltage:
220 V AC,230 V AC,240 V AC
Overload Protection:
Yes
Package Contents:
  • SmartPro SMX1500XLRT2UN 1500VA Rack/Tower UPS
  • WEBCARDLX Network Management Card
  • USB Cable
  • DB9 Cable
  • EPO Cable
  • 2 x C13-to-C14 AC power cords
  • Rack-mounting Hardware
  • Owner's Manual
Phase:
Single Phase
Plug/Connector Type:
IEC 60320 C14
Product Line:
SmartPro
Product Model:
SMX1500XLRT2UN
Product Type:
Line-interactive UPS
Rack Height:
2U
Receptacle Detail:
8 x IEC 60320 C13
Receptacle Type:
IEC 60320 C13
Replaceable Battery:
Yes
Serial Port:
Yes
Sound Emission (A-Weighted):
45 dB(A)
Status Indicators:

Front Panel LCD Information And Configuration Screen:

  • UPS and Site Power Status
  • Operating Data
  • Plus Configuration Of Voltage
  • Frequency
  • Operating Mode
  • Alarm Function and A Variety Of Additional Options
Storage Temperature:
5°F (-15°C) - 122°F (50°C)
Surge Energy Rating:
350 J
Thermal Dissipation:
201.93 W
Transfer Time:
6 ms
Typical Battery Recharge Time:
4.50 Hour
USB (HID Compliant) Port:
Yes
Waveform Type:
Pure Sine Wave
