Black Box KVM Extender - 4K@60Hz, HDMI 1.4, USB 2.0, CAT5e/6/6A
Use the KVM Extenders to send high-resolution 4K@60Hz (4:2:0 8-bit) video as well as signals for USB keyboards, mice, and other human interface devices (HID), and power and control signals. The extender includes a local unit that attaches to the CPU and a remote unit that connects the user's KVM console. But you can also plug in a monitor on the local side - which is great for monitoring and administration right at the computer. Requires only one power supply.
- Four USB Type-A inputs for keyboard, mouse, or additional peripherals
- HDMI 1.4 Compliance
- An analog audio pass through from Transmitter to Receiver
- Locking power supply prevents the power from being accidentally disconnected
- Transmit video, analog stereo, power, RS-232 and USB 2.0 signals
- With integrated 48V PoC, only one power supply is needed to power both units
- Extend uncompressed 4Kx2K@60Hz and 1080p@60Hz up to 100 meters over CAT6, CAT6A cables and up to 90 meters over CAT5 cable
Call for Availability
Shipping calculated at checkout
Use the KVM Extenders to send high-resolution 4K@60Hz (4:2:0 8-bit) video as well as signals for USB keyboards, mice, and other human interface devices (HID), and power and control signals. The extender includes a local unit that attaches to the CPU and a remote unit that connects the user's KVM console. But you can also plug in a monitor on the local side - which is great for monitoring and administration right at the computer. Requires only one power supply.
- Four USB Type-A inputs for keyboard, mouse, or additional peripherals
- HDMI 1.4 Compliance
- An analog audio pass through from Transmitter to Receiver
- Locking power supply prevents the power from being accidentally disconnected
- Transmit video, analog stereo, power, RS-232 and USB 2.0 signals
- With integrated 48V PoC, only one power supply is needed to power both units
- Extend uncompressed 4Kx2K@60Hz and 1080p@60Hz up to 100 meters over CAT6, CAT6A cables and up to 90 meters over CAT5 cable
- 1 x Transmitter
- 1 x Receiver
- 1 x 12VDC, 2A Power Supply
- 4 x Power Cords (US, UK, EU, AU)
- 2 x 3-Pin Phoenix connectors
- 2 x Mounting brackets + 4 screws
