Avigilon Alta A800 Cloud Connector

MFG SKU: APP-800-32-DG

Get proactive about safety and security with Avigilon's Dome cameras.

Alta Aware License Term (Includes 30 Days Cloud Storage)
$179

In stock

Regular price $9,279.00

Shipping calculated at checkout

Cloud Storage & Accessories

Product Specifications

Cloud Connector Specifications

Number of Cameras Supported 50 cameras
Video Storage Up to 48TB (raw), 32TB (net)
Local Display Local display enables video views from Alta Video deployments to be sent to a monitor connected to the on-board video connections on Alta A200, A600, and A800 Cloud Connectors.

Component Specifications

Processor Intel Core i5 14500
GPU Nvidia RTX 4060
RAM 32GB: 2 x 16 GB, DDR5, 4400 MT/s, non-ECC
Network Interface 2.5Gb BaseT + 1Gb BaseT
SSD (system drive) 256 GB, M.2, PCIe NVMe, SSD, Class 35
HDD (video storage) 3x 12TB (32TB net) Surveillance-grade SATA drives
HDD Resiliency Avigilon Alta adaptive block-level erasure coding, allowing 1 disk failure
Operating System Avigilon Alta Linux-based hardened OS

Electrical Specifications

Input 90VAC-264VAC 7A (Max)
Power Supply 500W internal
Power Usage (at 80% load) 278W

Environmental Specifications

Storage (temperature) -40°F to 158°F (-40°C to 70°C)
Operating (temperature) 41°F to 113°F (5°C to 45°C)
Storage (relative humidity) 5% to 95% (non-condensing, Max dew point temperature = 33°C)
Operating (relative humidity) 20% to 85% (non-condensing), Max dew point temperature = 26°C)
Storage (Vibration) 2.0 Grms random at 5 Hz-500 Hz
Operating (vibration) 0.52 Grms random at 5 Hz to 350 Hz
Storage (max. shock pulse) 105G half-sine pulse (2.5ms)
Operating (max. shock pulse) 40G Bottom half-sine pulse (2.5ms)

Warranty

Software Support Avigilon Alta Technical Support
Cloud Connector Five year Warranty, with next day OEM support on-site
HDD RMA via Partner or Avigilon Alta Technical Support

Outline Dimensions

Height 14.68 in. (372.90 mm)
Width 6.81 in. (173.00 mm)
Depth 16.54 in. (420.20 mm)
Weight Maximum: 35.38 lb (16.05 kg)

Product Resources

WHY AVIGILON?

Avigilon delivers advanced security solutions powered by AI-driven video analytics, providing faster incident detection and proactive threat response. With end-to-end systems designed for scalability and reliability, Avigilon ensures unmatched performance for organizations of all sizes.

LEARN MORE

CLOUD AND ON-PREM

Avigilon offers flexible deployment options with cloud-based Alta for remote access and simplified management, or on-premise Unity for full local control and data ownership. Both platforms deliver powerful video analytics and seamless integration to meet diverse security needs.
