ARCHIVED Server Technology Switched PDU - 2.8kW, C1W24VS-1DFA25A5
SKU: C1W24VS-1DFA25A5
The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- PDU is reliable for power protection and management solutions
- Remotely control individual outlets for rebooting of locked equipment with switched PDUs
- NEMA 5-20R receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides dependable power output with maximum efficiency
- NEMA L5-30P plug/connector type for better, dependable connectivity and desired power output
- 120 V AC input voltage for better reliance and maximum dependability
- 120 V AC output voltage for optimal performance with maximum feasibility
Call for Availability
Regular price
$1,318
Shipping calculated at checkout
The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- PDU is reliable for power protection and management solutions
- Remotely control individual outlets for rebooting of locked equipment with switched PDUs
- NEMA 5-20R receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides dependable power output with maximum efficiency
- NEMA L5-30P plug/connector type for better, dependable connectivity and desired power output
- 120 V AC input voltage for better reliance and maximum dependability
- 120 V AC output voltage for optimal performance with maximum feasibility
Country of Origin:
United States
Input Current:
30 A
Input Voltage:
120 V AC
Limited Warranty:
2 Year
Management:
- SSH
- SMTP
- Syslog
- HTTP/HTTPS
- TLSv1.2
- SSHv2
- Telnet
- SNMPv2c and v3 (GET, SET, Traps)
- IPv4 and IPv6
- LDAPv3/LDAPS
- TACACS+
- RADIUS
- FTP/SFTP
Manufacturer:
Legrand Group
Manufacturer Website Address:
http://www.servertech.com
Mount Type:
Rack-mountable
Network (RJ-45):
Yes
Output Voltage:
120 V AC
PDU Type:
Switched
Phase:
Three Phase
Plug/Connector Type:
NEMA L5-30P
Power Rating (Watt):
2800 W
Product Model:
C1W24VS-1DFA25A5
Product Series:
PRO1
Product Type:
PDU
Protection Type:
Fuse
Rack Height:
0U
Receptacle Detail:
24 x NEMA 5-20R
Receptacle Type:
NEMA 5-20R
