ARCHIVED Server Technology Smart PDU - 17.3kW, C1S39CS-5CPD2T444
SKU: C1S39CS-5CPD2T444
The Server Technology® PRO1 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Smart Master" PDU can be connected to as many as three (with optional module) PRO1 Smart "Link"� PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration."
- With PDUs decisions for load balancing and minimizing extra cost can be managed
- Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides dependable power output with maximum efficiency
- NEMA L22-30P plug/connector type for better, dependable connectivity and desired power output
- 415 V input voltage for optimal performance with maximum usability
Call for Availability
Regular price
$2,174
Shipping calculated at checkout
The Server Technology® PRO1 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Smart Master" PDU can be connected to as many as three (with optional module) PRO1 Smart "Link"� PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration."
- With PDUs decisions for load balancing and minimizing extra cost can be managed
- Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides dependable power output with maximum efficiency
- NEMA L22-30P plug/connector type for better, dependable connectivity and desired power output
- 415 V input voltage for optimal performance with maximum usability
Form Factor:
Rack/Tower
Input Current:
30 A
Input Voltage:
415 V
Limited Warranty:
2 Year
Manufacturer:
Legrand Group
Manufacturer Website Address:
http://www.servertech.com
Mount Type:
Cabinet-mountable,Rack-mountable
Network (RJ-45):
Yes
Package Contents:
PDU Type:
Monitored
Phase:
Three Phase
Plug/Connector Detail:
1 x NEMA L22-30P
Plug/Connector Type:
NEMA L22-30P
Power Rating (Watt):
17.30 kW
Product Line:
PRO1
Product Model:
C1S39CS-5CPD2T444
Product Series:
Smart
Product Type:
PDU
Protection Type:
Overcurrent Protection,Overload Protection,Circuit Protection
Receptacle Detail:
27 x IEC 60320 C13,12 x IEC 60320 C19
Receptacle Type:
IEC 60320 C13,IEC 60320 C19
