APC Smart-UPS Ultra On-Line, 10000VA, Lithium-ion, Rack/Tower 4U, 208V, 2 L6-20R + 2 L6-30R NEMA outlets, Network Card, Extended runtime, W/rail kit
SKU: SRTL10KRM4UT
With Smart-UPS™ Ultra you can put up to 10000W of power protection in places never before possible. Make installation effortless with a 10kW UPS that is 30% smaller and lighter than any comparable UPS. The auto-rotating touch screen display makes switching between horizontal and vertical mounting options instantaneous. EcoStruxure Ready Smart-UPS provides visibility anywhere, anytime. Standard warranty, 5 years repair or replace.
- 4U, 10000VA/10000W rack/ tower convertible UPS with autorotating LCD display
- Add up to 10 external battery packs (SRTL180RM2UBP) for extended runtime
- Lithium-ion batteries lasts 3X VRLA UPS, no need to replace the battery during the life of the UPS
- EcoStruxureâ"� Ready for remote monitoring and management
- 1-Year Secure Network Management Card subscription included
- 5-year warranty on UPS and internal batteries
- Wireless communication capable with optional WiFi Device accessory (AP9834)
Call for Availability
Regular price
$26,370
Shipping calculated at checkout
With Smart-UPS™ Ultra you can put up to 10000W of power protection in places never before possible. Make installation effortless with a 10kW UPS that is 30% smaller and lighter than any comparable UPS. The auto-rotating touch screen display makes switching between horizontal and vertical mounting options instantaneous. EcoStruxure Ready Smart-UPS provides visibility anywhere, anytime. Standard warranty, 5 years repair or replace.
- 4U, 10000VA/10000W rack/ tower convertible UPS with autorotating LCD display
- Add up to 10 external battery packs (SRTL180RM2UBP) for extended runtime
- Lithium-ion batteries lasts 3X VRLA UPS, no need to replace the battery during the life of the UPS
- EcoStruxureâ"� Ready for remote monitoring and management
- 1-Year Secure Network Management Card subscription included
- 5-year warranty on UPS and internal batteries
- Wireless communication capable with optional WiFi Device accessory (AP9834)
Additional Warranty Information:
5 years repair or replace
Battery Chemistry:
Lithium Ion (Li-Ion)
Country of Origin:
Philippines
DC System Voltage:
180 V DC
Display:
LCD
Efficiency:
96.4%
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),China Restriction of Hazardous Substances (China RoHS)
EPO Port:
Yes
Form Factor:
Rack/Tower
Input Frequency:
50 Hz,60 Hz
Input Voltage:
208 V AC
Limited Warranty:
5 Year
Load Capacity (VA):
10000 VA
Load Capacity (Watt):
10 kW
Manufacturer:
Schneider Electric SA
Manufacturer Website Address:
http://www.schneider-electric.com
Maximum Operating Elevation:
10000 ft
Maximum Operating Temperature:
104°F (40°C)
Maximum Storage Elevation:
50000 ft
Network (RJ-45):
Yes
Network Management:
Network Card
Output Frequency:
50 Hz,60 Hz
Output Voltage:
208 V AC
Packaged Quantity:
1 / Pack
Package Contents:
Plug/Connector Type:
Hard Wire 3-wire
Product Color:
Silver Gray
Product Line:
Smart-UPS Ultra
Product Type:
Double Conversion Online UPS
Rack Height:
4U
Receptacle Detail:
1 x Hard Wire 3-wire (2PH + G),2 x NEMA L6-30R,2 x NEMA L6-20R
Receptacle Type:
Hard Wire 3-wire (2PH + G),NEMA L6-30R,NEMA L6-20R
Sound Emission:
55 dB
Storage Relative Humidity:
0% - 95%
Storage Temperature:
5°F (-15°C) - 113°F (45°C)
Surge Energy Rating:
1410 J
Typical Battery Recharge Time:
1.50 Hour
USB:
Yes
Waveform Type:
Sine Wave
