Advantech 8GE + 2G SFP + 2 VDSL2 port Managed Industrial Switch
SKU: EKI-7712G-2FV-AE
The EKI-7712G-2FV and EKI-7708G-2FV provide 8/4 Gigabit ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. These switches provide abundant port options, thus providing support for connecting a range of different devices. They also come embedded with Advantech IXM function for fast deployment, thus have a marked impact in saving on engineering time and costs. This series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X-Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. These switches also incorporate the latest VDSL2 technology and can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line systems), thus avoiding unnecessary costs associated with rewiring. It can substantially extend Ethernet service on UTP wire with distances up to 3000 m, and even with a rate of 100Mbps for up to 400 m on standard CAT-5e2 cable.
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)
- IXM function enables fast deployment
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
- NEMA TS2 for traffic control
- Provide 100/100 Mbps up to 400m over CAT 5e
- EN50121-4 approval for railway trackside deployment
- Dual 12 ~ 48 VDC power input and 1 relay output
Call for Availability
Regular price
$1,559.89
Sale price
$1,879.65
On Sale
Shipping calculated at checkout
The EKI-7712G-2FV and EKI-7708G-2FV provide 8/4 Gigabit ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. These switches provide abundant port options, thus providing support for connecting a range of different devices. They also come embedded with Advantech IXM function for fast deployment, thus have a marked impact in saving on engineering time and costs. This series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X-Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. These switches also incorporate the latest VDSL2 technology and can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line systems), thus avoiding unnecessary costs associated with rewiring. It can substantially extend Ethernet service on UTP wire with distances up to 3000 m, and even with a rate of 100Mbps for up to 400 m on standard CAT-5e2 cable.
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)
- IXM function enables fast deployment
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
- NEMA TS2 for traffic control
- Provide 100/100 Mbps up to 400m over CAT 5e
- EN50121-4 approval for railway trackside deployment
- Dual 12 ~ 48 VDC power input and 1 relay output
Country of Origin:
China
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet
Expansion Slot Type:
SFP (mini-GBIC)
Form Factor:
DIN Rail Mountable,Wall Mountable
Layer Supported:
2
Limited Warranty:
5 Year
Manageable:
Yes
Manufacturer:
Advantech Co., Ltd
Manufacturer Website Address:
http://www.advantech.com
Media Type Supported:
Twisted Pair,Optical Fiber
Modular:
Yes
Network Technology:
10/100/1000Base-T,1000Base-X
Number of SFP Slots:
2
Port/Expansion Slot Details:
8 x Gigabit Ethernet Network,2 x Gigabit Ethernet Expansion Slot,2 x Expansion Slot
Product Model:
EKI-7712G-2FV
Product Type:
Ethernet Switch
Shared SFP Slot:
No
Total Number of Network Ports:
8
