Advantech 8G+4SFP Port Gigabit Unmanaged Redundant Industrial PoE Switch
SKU: EKI-2712G-4FPI-AE
EKI-2712G-4FPI supports 8 Gigabit IEEE 802.3 af/at PoE ports and 4 SFP (mini-GBIC) ports. They can provide up to 30 watts per port to fulfill high power consumption PD (Power Device). The switch also features a wide -40° to 75°C operating temperature and NEMA TS2 rating, making the switch an ideal solution for use in traffic applications and have successfully passed the EN50121-4 European railway standard requirements of emission and immunity for railway platforms and trackside deployment.
- Dual 48 VDC power input and 1 x relay output
- EN50121-4 approval for railway trackside deployment
- -40 ~ 75°C wide-range operating temperature
- NEMA TS2 for traffic control
- SFP socket for easy and flexible fiber expansion
- 8 x IEEE 802.3 af/at PoE Gigabit ports + 4 x SFP ports
Call for Availability
Regular price
$1,003.25
Shipping calculated at checkout
EKI-2712G-4FPI supports 8 Gigabit IEEE 802.3 af/at PoE ports and 4 SFP (mini-GBIC) ports. They can provide up to 30 watts per port to fulfill high power consumption PD (Power Device). The switch also features a wide -40° to 75°C operating temperature and NEMA TS2 rating, making the switch an ideal solution for use in traffic applications and have successfully passed the EN50121-4 European railway standard requirements of emission and immunity for railway platforms and trackside deployment.
- Dual 48 VDC power input and 1 x relay output
- EN50121-4 approval for railway trackside deployment
- -40 ~ 75°C wide-range operating temperature
- NEMA TS2 for traffic control
- SFP socket for easy and flexible fiber expansion
- 8 x IEEE 802.3 af/at PoE Gigabit ports + 4 x SFP ports
Country of Origin:
China
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet
Expansion Slot Type:
SFP (mini-GBIC)
Form Factor:
DIN Rail Mountable,Wall Mountable
Layer Supported:
2
Limited Warranty:
5 Year
Manageable:
No
Manufacturer:
Advantech Co., Ltd
Manufacturer Website Address:
http://www.advantech.com
Media Type Supported:
Twisted Pair,Optical Fiber
Modular:
Yes
Network Technology:
10/100/1000Base-T,1000Base-X
Number of SFP Slots:
4
Port/Expansion Slot Details:
8 x Gigabit Ethernet Network,4 x Gigabit Ethernet Expansion Slot
Product Model:
EKI-2712G-4FPI
Product Type:
Ethernet Switch
Total Number of Expansion Slots:
4.0
Total Number of Network Ports:
8
