Advantech 4GE PoE + 2G SFP + 2 VDSL2 Port Managed Redundant Industrial Switch
SKU: EKI-7708G-2FVP-AE
The EKI-7712G and EKI-7708G-2FVP support 8/4 Gigabit PoE ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. They offer abundant port options for connecting many different device types. The embedded Advantech IXM function facilitates fast deployment, which can dramatically save on engineering time and costs. The series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. The switches also incorporate the latest VDSL2 technology, meaning that this SFP module can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line), thus avoiding the cost of rewiring. Furthermore, they can drastically extend Ethernet service on UTP wire up to 3000 m, and even with a rate of 100 Mbps up to 400 m on a standard CAT 5e2 wire cable.
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- IXM function enables fast deployment
- Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
- NEMA TS2 for traffic control
- EN50121-4 approval for railway trackside deployment
- Dual 48 VDC (46 to 57 VDC) power input and 1 relay output
- Provide 100/100 Mbps up to 400m over CAT 5e
Call for Availability
Regular price
$1,189.22
Sale price
$1,432.99
On Sale
Shipping calculated at checkout
The EKI-7712G and EKI-7708G-2FVP support 8/4 Gigabit PoE ports, 2 Gigabit SFP ports, and 2 VDSL2 ports. They offer abundant port options for connecting many different device types. The embedded Advantech IXM function facilitates fast deployment, which can dramatically save on engineering time and costs. The series also support NMS to help IT managers with networking maintenance and failure prevention. Finally, they are equipped with X Ring Pro redundancy for ultra-high-speed recovery times of <20 ms. The switches also incorporate the latest VDSL2 technology, meaning that this SFP module can be easily adapted to existing applications with existing 2-wire cable (e.g., phone line), thus avoiding the cost of rewiring. Furthermore, they can drastically extend Ethernet service on UTP wire up to 3000 m, and even with a rate of 100 Mbps up to 400 m on a standard CAT 5e2 wire cable.
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP and MSTP (802.1w/1D/1s)
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- IXM function enables fast deployment
- Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB
- NEMA TS2 for traffic control
- EN50121-4 approval for railway trackside deployment
- Dual 48 VDC (46 to 57 VDC) power input and 1 relay output
- Provide 100/100 Mbps up to 400m over CAT 5e
Country of Origin:
China
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet
Expansion Slot Type:
SFP (mini-GBIC)
Form Factor:
DIN Rail Mountable,Wall Mountable
Layer Supported:
2
Limited Warranty:
5 Year
Manageable:
Yes
Manufacturer:
Advantech Co., Ltd
Manufacturer Website Address:
http://www.advantech.com
Media Type Supported:
Twisted Pair,Optical Fiber
Modular:
Yes
Network Technology:
10/100/1000Base-T,1000Base-X
Number of SFP Slots:
2
Port/Expansion Slot Details:
4 x Gigabit Ethernet Network,2 x Gigabit Ethernet Expansion Slot,2 x Expansion Slot
Product Model:
EKI-7708G-2FVP
Product Type:
Ethernet Switch
Shared SFP Slot:
No
Total Number of Network Ports:
4
