AddOn 10/100Base-TX(RJ-45) to 100Base-LX(SC) SMF 1310nm 20km Media Converter Card for our rack or Standalone Systems
SKU: ADD-MCC1MSM20
This is a media converter card that converts a 10/100Base-TX(RJ-45) to 100Base-LX(SC) via a 1310nm single-mode fiber (SMF) SC connector, which allows distance reach up to 20km. It provides a cost effective conversion from 10/100Base-TX(RJ-45) to 100Base-LX fiber, while extending the network reach beyond the 100m reach limitation of copper. This device can be managed if used in our managed rack system or unmanaged with our unmanaged rack system or standalone chassis enclosure. Our media converters are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs.
- With Optical Fiber cable, get the desired data transfer rate up to a required distance
- Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
- With 10/100Base-TX technology get up to 100Mbps data transfer rate over optical fiber cable
- Takes minimal energy and effort to get installed internally
Call for Availability
Regular price
$80.07
Sale price
$130.00
On Sale
Shipping calculated at checkout
This is a media converter card that converts a 10/100Base-TX(RJ-45) to 100Base-LX(SC) via a 1310nm single-mode fiber (SMF) SC connector, which allows distance reach up to 20km. It provides a cost effective conversion from 10/100Base-TX(RJ-45) to 100Base-LX fiber, while extending the network reach beyond the 100m reach limitation of copper. This device can be managed if used in our managed rack system or unmanaged with our unmanaged rack system or standalone chassis enclosure. Our media converters are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs.
- With Optical Fiber cable, get the desired data transfer rate up to a required distance
- Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
- With 10/100Base-TX technology get up to 100Mbps data transfer rate over optical fiber cable
- Takes minimal energy and effort to get installed internally
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Fast Ethernet
Fiber Mode Supported:
Single-mode
Fiber Optic Cable Core/Cladding Specification:
9/125 µm
Fiber Optic Cable Wavelength:
1310 nm
Form Factor:
Internal
Limited Warranty:
3 Year
Manufacturer:
AddOn
Manufacturer Website Address:
http://www.addoncomputer.com
Maximum Distance Supported:
20 km
Media Type Supported:
Optical Fiber,Twisted Pair
Network (RJ-45):
Yes
Network Technology:
10/100Base-TX,100Base-LX
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
Packaged Quantity:
1
Product Model:
ADD-MCC1MSM20
Product Type:
Transceiver/Media Converter
TAA Compliant:
No
Total Number of Ports:
2
