2N Access Unit 2.0 RFID 125 KHZ
Do you need a good-looking access reader for your project? All the residents of luxury residences will be delighted with the 2N Access Unit 2.0. Select modern access with a mobile phone or fi ngerprint. Do you prefer conventional methods? We also o er an RFID card reader or keypad. Cannot decide? Select a combination of several methods in one device. But don't look for controllers in our portfolio. They are already an integral part of every reader.
- Ideal for residential projects
- Fastest Bluetooth technology
- You don't need a controller
- Quick installation and remote administration
- Flush mount or installation on glass
- Timeless solution
Call for Availability
Shipping calculated at checkout
Do you need a good-looking access reader for your project? All the residents of luxury residences will be delighted with the 2N Access Unit 2.0. Select modern access with a mobile phone or fi ngerprint. Do you prefer conventional methods? We also o er an RFID card reader or keypad. Cannot decide? Select a combination of several methods in one device. But don't look for controllers in our portfolio. They are already an integral part of every reader.
- Ideal for residential projects
- Fastest Bluetooth technology
- You don't need a controller
- Quick installation and remote administration
- Flush mount or installation on glass
- Timeless solution
- Power supply: PoE and/or 12 V/1 A DC
- PoE: 802.3af (Class 0-12.95 W)
- LAN: 10/100BASE-TX with Auto-MDIX, RJ-45 modular jack
- Recommended cabling: Cat-5e or better
- Active switch output: 8 to 12 V DC/max 600 mA
- Passive switch: NO/NC contacts, up to 30 V/1 A AC/DC
- Inputs: 2 inputs - in passive/active mode (-30 V to +30 V DC)
- OFF = open or Uin> 1.5 V
- ON = short-circuit or Uin< 1.5 V
- Tamper switch: native part of the 2N Access Unit 2.0
- Audio: buzzer (97dBA)
- Supported protocols: DHCP opt. 66, SMTP, TFTP, HTTP, HTTPS, Syslog
- Frame: robust zinc cast frame with surface finish (nickel and black color)
- Operating temperature: -40°F to +140°F
- Storage temperature: -40°F to +158°F
- Operating relative humidity: 10%-95% (non-condensing)
- 1 module: 4.2 (W) x 5.11 (H) x 1.10 (D) inch
- 1 module: 5.11 (W) x 6.02 (H) x 0.19 (D) inch
- 1 module: 4.25 (W) x 5.15 (H) x 1.77 (D) inch
- IP54
- IK08
- Axis 2N IP Access Control Unit
- Axis 2N HID Prox Proximity Card
Axis 2N Card Reader:
- EM4100
- EM4102
