Bosch

Filter and sort
Clear all

  • Call for availability

  • Call for availability


Illuminator, 850nm, short range

IIR-50850-SR

  • Additional Information: Power
    • Power supply: 12 to 32 VDC or 24 VAC ±10%
    • Power consumption: 13 W
    Optical
    • Wavelength: 850 nm or 940 nm
    • IR control: Adjustable IR intensity (10% to 100%)
    • Day/night switch: Photocell, sensitivity adjustable (20 lx to 70 lx)
    • Beam angles: 10°, 20°, 30°, 60°, 80°, and 95°
    Range 850 nm
    • Beam pattern diffuser: Achievable Distance, HFOV
    • 10°: 156 m (510 ft) , 27 m (89 ft)
    • 20°: 106 m (348 ft) , 37 m (123 ft)
    • 30°: 78 m (255 ft) , 42 m (137 ft)
    • 60°: 49 m (162 ft) , 57 m (187 ft)
    • 80°: 35 m (116 ft) , 59 m (195 ft)
    • 95°: 25 m (81 ft) , 54 m (177 ft)
    Range 940 nm
    • Beam pattern diffuser Achievable Distance, HFOV
    • 10°: 95 m (313 ft) , 17 m (55 ft)
    • 20°: 57 m (186 ft) , 20 m (65 ft)
    • 30°: 46 m (151 ft) , 25 m (81 ft)
    • 60°: 28 m (93 ft) , 33 m (107 ft)
    • 80°: 21 m (70 ft) , 36 m (117 ft)
    • 95°: 14 m (46 ft) , 31 m (101 ft)
    Mechanical
    • Mount: Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
    • Cable: 3 m (9 ft)
    • Bracket dimensions (W x H x D): 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
    • Bracket weight: 0.2 kg (0.44 lbs
    Environmental
    • Operation Temperature Range: -50 °C to +50 °C (-58 °F to +122 °F)
  • Application/Usage: Surveillance
  • Color Family: Black
  • Country of Origin: United Kingdom
View all specs
Additional Information: Power
  • Power supply: 12 to 32 VDC or 24 VAC ±10%
  • Power consumption: 13 W
Optical
  • Wavelength: 850 nm or 940 nm
  • IR control: Adjustable IR intensity (10% to 100%)
  • Day/night switch: Photocell, sensitivity adjustable (20 lx to 70 lx)
  • Beam angles: 10°, 20°, 30°, 60°, 80°, and 95°
Range 850 nm
  • Beam pattern diffuser: Achievable Distance, HFOV
  • 10°: 156 m (510 ft) , 27 m (89 ft)
  • 20°: 106 m (348 ft) , 37 m (123 ft)
  • 30°: 78 m (255 ft) , 42 m (137 ft)
  • 60°: 49 m (162 ft) , 57 m (187 ft)
  • 80°: 35 m (116 ft) , 59 m (195 ft)
  • 95°: 25 m (81 ft) , 54 m (177 ft)
Range 940 nm
  • Beam pattern diffuser Achievable Distance, HFOV
  • 10°: 95 m (313 ft) , 17 m (55 ft)
  • 20°: 57 m (186 ft) , 20 m (65 ft)
  • 30°: 46 m (151 ft) , 25 m (81 ft)
  • 60°: 28 m (93 ft) , 33 m (107 ft)
  • 80°: 21 m (70 ft) , 36 m (117 ft)
  • 95°: 14 m (46 ft) , 31 m (101 ft)
Mechanical
  • Mount: Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
  • Cable: 3 m (9 ft)
  • Bracket dimensions (W x H x D): 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
  • Bracket weight: 0.2 kg (0.44 lbs
Environmental
  • Operation Temperature Range: -50 °C to +50 °C (-58 °F to +122 °F)
Application/Usage: Surveillance
Color Family: Black
Country of Origin: United Kingdom
Device Supported: Surveillance Camera
Durability: Vandal Resistant
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Features: Interchangeable Lens,Adjustable,Robust,Adjustable Built-in Photocell,Adjustable Light Intensity,Self-cleaning Lens Coating,IP66,Surface Mount,Night Vision,Thermal Protection
Impact Protection (IK) Rating: IK09
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Product Color: Black
Product Material: Anodized Aluminum,Polycarbonate,Stainless Steel
Product Type: Infrared Illuminator
$331

Shipping calculated at checkout

Regular price $331

View details

  • Call for availability

  • Call for availability


Illuminator, 940nm, extra range

IIR-50940-XR

  • Additional Information:

    Power

    • Power supply x 12 to 32 VDC or 24 VAC ±10%
    • Power consumption x 52 W

    Optical

    • Wavelength x 850 nm or 940 nm
    • IR control x Adjustable IR intensity (10% to 100%)
    • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
    • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

    Range 850 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 308 m (1010 ft) 54 m (177 ft)
    • 20° x 210 m (689 ft) 74 m (243 ft)
    • 30� x 154 m (505 ft) 83 m (271 ft)
    • 60° x 98 m (322 ft) 113 m (371 ft)
    • 80° x 70 m (230 ft) 117 m (385 ft)
    • 95� x 49 m (161 ft) 107 m (351 ft)

    Range 940 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 189 m (620 ft) 33 m (108 ft)
    • 20° x 112 m (367 ft) 39 m (130 ft)
    • 30� x 91 m (299 ft) 49 m (160 ft)
    • 60° x 56 m (184 ft) 65 m (212 ft)
    • 80° x 42 m (138 ft) 70 m (231 ft)
    • 95� x 28 m (92 ft) 61 m (201 ft)

    Mechanical

    • Housing x Robust anodized aluminum extrusion, black
    • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
    • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
    • Cable x 3 m (9 ft)
    • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
    • Bracket weight x 0.2 kg (0.44 lbs)

    Environmental

    • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
  • Application/Usage: Surveillance,Indoor,Outdoor
  • Certifications & Standards: IP66
  • Color Family: Black
View all specs
Additional Information:

Power

  • Power supply x 12 to 32 VDC or 24 VAC ±10%
  • Power consumption x 52 W

Optical

  • Wavelength x 850 nm or 940 nm
  • IR control x Adjustable IR intensity (10% to 100%)
  • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
  • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

Range 850 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 308 m (1010 ft) 54 m (177 ft)
  • 20° x 210 m (689 ft) 74 m (243 ft)
  • 30� x 154 m (505 ft) 83 m (271 ft)
  • 60° x 98 m (322 ft) 113 m (371 ft)
  • 80° x 70 m (230 ft) 117 m (385 ft)
  • 95� x 49 m (161 ft) 107 m (351 ft)

Range 940 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 189 m (620 ft) 33 m (108 ft)
  • 20° x 112 m (367 ft) 39 m (130 ft)
  • 30� x 91 m (299 ft) 49 m (160 ft)
  • 60° x 56 m (184 ft) 65 m (212 ft)
  • 80° x 42 m (138 ft) 70 m (231 ft)
  • 95� x 28 m (92 ft) 61 m (201 ft)

Mechanical

  • Housing x Robust anodized aluminum extrusion, black
  • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
  • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
  • Cable x 3 m (9 ft)
  • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
  • Bracket weight x 0.2 kg (0.44 lbs)

Environmental

  • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
Application/Usage: Surveillance,Indoor,Outdoor
Certifications & Standards: IP66
Color Family: Black
Country of Origin: United Kingdom
Device Supported: Surveillance Camera
Durability: Vandal Resistant
Environmentally Friendly: Yes
Features: Surface Mount,Adjustable Built-in Photocell,Adjustable Light Intensity,Interchangeable Lens,Self-cleaning Lens Coating,Night Vision,Electronic Protection,Adjustable,IP66,Easy Installation
Input Voltage: 12 V DC,32 V DC,24 V AC
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Product Color: Black
Product Material: Anodized Aluminum,Polycarbonate
Product Type: Infrared Illuminator
$933

Shipping calculated at checkout

Regular price $933

View details

  • Call for availability

  • Call for availability


Illuminator, 940nm, long range

IIR-50940-LR

  • Additional Information:

    Power

    • Power supply x 12 to 32 VDC or 24 VAC ±10%
    • Power consumption x 39 W

    Optical

    • Wavelength x 850 nm or 940 nm
    • IR control x Adjustable IR intensity (10% to 100%)
    • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
    • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

    Range 850 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 268 m (881 ft) 47 m (154 ft)
    • 20° x 183 m (640 ft) 65 m (212 ft)
    • 30� x 134 m (440 ft) 72 m (236 ft)
    • 60° x 85 m (280 ft) 99 m (324 ft)
    • 80° x 61 m (200 ft) 102 m (336 ft)
    • 95� x 43 m (140 ft) 93 m (306 ft)

    Range 940 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 165 m (540 ft) 29 m (95 ft)
    • 20° x 98 m (320 ft) 34 m (113 ft)
    • 30� x 79 m (260 ft) 42 m (139 ft)
    • 60° x 49 m (160 ft) 56 m (185 ft)
    • 80° x 37 m (120 ft) 61 m (202 ft)
    • 95� x 24 m (80 ft) 53 m (175 ft)

    Mechanical

    • Housing x Robust anodized aluminum extrusion, black
    • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
    • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
    • Cable x 3 m (9 ft)
    • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
    • Bracket weight x 0.2 kg (0.44 lbs)

    Environmental

    • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
  • Application/Usage: Surveillance
  • Certifications & Standards: IP66
  • Color Family: Black
View all specs
Additional Information:

Power

  • Power supply x 12 to 32 VDC or 24 VAC ±10%
  • Power consumption x 39 W

Optical

  • Wavelength x 850 nm or 940 nm
  • IR control x Adjustable IR intensity (10% to 100%)
  • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
  • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

Range 850 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 268 m (881 ft) 47 m (154 ft)
  • 20° x 183 m (640 ft) 65 m (212 ft)
  • 30� x 134 m (440 ft) 72 m (236 ft)
  • 60° x 85 m (280 ft) 99 m (324 ft)
  • 80° x 61 m (200 ft) 102 m (336 ft)
  • 95� x 43 m (140 ft) 93 m (306 ft)

Range 940 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 165 m (540 ft) 29 m (95 ft)
  • 20° x 98 m (320 ft) 34 m (113 ft)
  • 30� x 79 m (260 ft) 42 m (139 ft)
  • 60° x 49 m (160 ft) 56 m (185 ft)
  • 80° x 37 m (120 ft) 61 m (202 ft)
  • 95� x 24 m (80 ft) 53 m (175 ft)

Mechanical

  • Housing x Robust anodized aluminum extrusion, black
  • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
  • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
  • Cable x 3 m (9 ft)
  • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
  • Bracket weight x 0.2 kg (0.44 lbs)

Environmental

  • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
Application/Usage: Surveillance
Certifications & Standards: IP66
Color Family: Black
Country of Origin: United Kingdom
Device Supported: Surveillance Camera
Durability: Vandal Resistant
Environmentally Friendly: Yes
Features: Surface Mount,IP66,Robust
Input Voltage: 12 V DC,32 V DC,24 V AC
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Product Color: Black
Product Material: Anodized Aluminum,Polycarbonate
Product Type: Infrared Illuminator
$792

Shipping calculated at checkout

Regular price $792

View details

  • Call for availability

  • Call for availability


Illuminator, 940nm, medium range

IIR-50940-MR

  • Additional Information:

    Power

    • Power supply x 12 to 32 VDC or 24 VAC ±10%
    • Power consumption x 26 W

    Optical

    • Wavelength x 850 nm or 940 nm
    • IR control x Adjustable IR intensity (10% to 100%)
    • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
    • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

    Range 850 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 220 m (722 ft) 38 m (126 ft)
    • 20° x 150 m (492 ft) 53 m (174 ft)
    • 30� x 110 m (361 ft) 59 m (193 ft)
    • 60° x 70 m (230 ft) 81 m (265 ft)
    • 80° x 50 m (164 ft) 84 m (275 ft)
    • 95� x 35 m (115 ft) 76 m (251 ft)

    Range 940 nm

    • Beam pattern diffuser x Achievable Distance* HFOV
    • 10� x 135 m (443 ft) 24 m (77 ft)
    • 20° x 80 m (262 ft) 28 m (93 ft)
    • 30� x 65 m (213 ft) 35 m (114 ft)
    • 60° x 40 m (131 ft) 46 m (152 ft)
    • 80° x 30 m (98 ft) 50 m (165 ft)
    • 95� x 20 m (66 ft) 44 m (143 ft)

    Mechanical

    • Housing x Robust anodized aluminum extrusion, black
    • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
    • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
    • Cable x 3 m (9 ft)
    • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
    • Bracket weight x 0.2 kg (0.44 lbs)

    Environmental

    • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
  • Application/Usage: Indoor,Outdoor,Surveillance
  • Color Family: Black
  • Country of Origin: United Kingdom
View all specs
Additional Information:

Power

  • Power supply x 12 to 32 VDC or 24 VAC ±10%
  • Power consumption x 26 W

Optical

  • Wavelength x 850 nm or 940 nm
  • IR control x Adjustable IR intensity (10% to 100%)
  • Day/night switch x Photocell, sensitivity adjustable (20 lx to 70 lx)
  • Beam angles x 10°, 20°, 30°, 60°, 80°, and 95°

Range 850 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 220 m (722 ft) 38 m (126 ft)
  • 20° x 150 m (492 ft) 53 m (174 ft)
  • 30� x 110 m (361 ft) 59 m (193 ft)
  • 60° x 70 m (230 ft) 81 m (265 ft)
  • 80° x 50 m (164 ft) 84 m (275 ft)
  • 95� x 35 m (115 ft) 76 m (251 ft)

Range 940 nm

  • Beam pattern diffuser x Achievable Distance* HFOV
  • 10� x 135 m (443 ft) 24 m (77 ft)
  • 20° x 80 m (262 ft) 28 m (93 ft)
  • 30� x 65 m (213 ft) 35 m (114 ft)
  • 60° x 40 m (131 ft) 46 m (152 ft)
  • 80° x 30 m (98 ft) 50 m (165 ft)
  • 95� x 20 m (66 ft) 44 m (143 ft)

Mechanical

  • Housing x Robust anodized aluminum extrusion, black
  • Front window x Polycarbonate high transmittance (vandal-resistant) with self-cleaning technology
  • Mount x Black powder coated stainless steel U-bracket (adjustable with M6 socket-head wrench)
  • Cable x 3 m (9 ft)
  • Bracket dimensions(W x H x D) x 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in)
  • Bracket weight x 0.2 kg (0.44 lbs)

Environmental

  • Operation Temperature Range x -50 °C to +50 °C (-58 °F to +122 °F)
Application/Usage: Indoor,Outdoor,Surveillance
Color Family: Black
Country of Origin: United Kingdom
Device Supported: Surveillance Camera
Features: Surface Mount,Night Vision,Self-cleaning Lens Coating,Interchangeable Lens,Adjustable Built-in Photocell,Adjustable Light Intensity,Robust,IP66,Adjustable
Input Voltage: 12 V DC,32 V DC,24 V AC
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Product Color: Black
Product Material: Polycarbonate,Anodized Aluminum
Product Type: Infrared Illuminator
$558

Shipping calculated at checkout

Regular price $558

View details

  • Call for availability

  • Call for availability


Illuminator, 940nm, short range

IIR-50940-SR

  • Application/Usage: Surveillance
  • Color Family: Black
  • Country of Origin: United Kingdom
  • Device Supported: Surveillance Camera
View all specs
Application/Usage: Surveillance
Color Family: Black
Country of Origin: United Kingdom
Device Supported: Surveillance Camera
Durability: Vandal Resistant
Features: Adjustable Light Intensity,Adjustable Built-in Photocell,Self-cleaning Lens Coating,Interchangeable Lens,Robust,IP66,Adjustable,Surface Mount,LED Illumination,Easy Installation
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Product Color: Black
Product Material: Anodized Aluminum,Polycarbonate,Stainless Steel
Product Type: Infrared Illuminator
$331

Shipping calculated at checkout

Regular price $331

View details

  • Call for availability

  • Call for availability


Interface module

OM-1

  • Country of Origin: China
  • Manufacturer: The Bosch Group
  • Manufacturer Website Address: http://www.bosch.com
  • Packaged Quantity: 1
View all specs
Country of Origin: China
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Package Contents:
  • Interface Module
  • 1 x Set of cable, connector and Screws
  • 1 x Installation Note
Product Type: Ethernet Interface Module
$1,295

Shipping calculated at checkout

Regular price $1,295

View details

  • Call for availability

  • Call for availability


IP Matrix extension for 8 cameras

VJD-IPM-X8C

  • Application/Usage: Surveillance Camera
  • Manufacturer: The Bosch Group
  • Manufacturer Website Address: http://www.bosch.com
  • Packaged Quantity: 1
View all specs
Application/Usage: Surveillance Camera
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Power Source: Power Supply
Product Type: IP Matrix Extension
$104

Shipping calculated at checkout

Regular price $104

View details

  • Call for availability

  • Call for availability


Paintable cover, 4 pcs

NDA-8000-PC

  • Certifications & Standards: EN 50130-5, class II
  • Color Family: Black
  • Compatibility: Bosch Flexidome IP 8000i Series Security Camera
  • Country of Origin: Taiwan
View all specs
Certifications & Standards: EN 50130-5, class II
Color Family: Black
Compatibility: Bosch Flexidome IP 8000i Series Security Camera
Country of Origin: Taiwan
Device Supported: Security Camera
Diameter: 7.1"
Durability: Corrosion Resistant
Features: Easy Installation
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 4 Piece
Package Contents:
  • Paintable Cover, 4 pcs
  • 1 x Quick Installation Guide
Product Color: Black
Product Material: Polycarbonate
Product Type: Security Camera Dome Cover
$77.10

Shipping calculated at checkout

Regular price $77.10

View details

  • Call for availability

  • Call for availability

1069870611.jpg?noimage=logo

Pendant interface plate, 110mm

NDA-5081-PIP

  • Application/Usage: Wall,Pipe,Indoor,Pendant
  • Color Family: White
  • Compatibility: Bosch
    • FLEXIDOME IP Micro 3000i Camera
    • FLEXIDOME Panoramic 5100i Camera
    • NDA-U-WMT Pendant Wall Mount
    • NDA-U-PMT Pendant Pipe Mount
  • Device Supported: Camera
View all specs
Application/Usage: Wall,Pipe,Indoor,Pendant
Color Family: White
Compatibility: Bosch
  • FLEXIDOME IP Micro 3000i Camera
  • FLEXIDOME Panoramic 5100i Camera
  • NDA-U-WMT Pendant Wall Mount
  • NDA-U-PMT Pendant Pipe Mount
Device Supported: Camera
Diameter: 4.33"
Durability: Weather Resistant,Vibration Resistant,Salt Resistant,Shock Resistant,Impact Resistant
Features: Robust,IK10
Form Factor: Wall Mountable
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Package Contents:
  • Pendant Interface Plate, 110mm
  • 5 x M4 T20 Screw
  • 1 x Quick Start Guide
Product Color: Signal White
Product Material: Aluminum
Product Type: Mounting Adapter
$26.50

Shipping calculated at checkout

Regular price $26.50

View details

  • Call for availability

  • Call for availability


Pendant interface plate, 148mm

NDA-5080-PIP

  • Application/Usage: Pendant
  • Color Family: White
  • Compatibility:

    Bosch FLEXIDOME 5100i Network Camera

  • Device Supported: Network Camera
View all specs
Application/Usage: Pendant
Color Family: White
Compatibility:

Bosch FLEXIDOME 5100i Network Camera

Device Supported: Network Camera
Diameter: 5.83"
Durability: Weather Resistant,Shock Resistant,Vibration Resistant,Salt Resistant,Impact Resistant
Features: Robust
Form Factor: Wall Mountable
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Package Contents:
  • Pendant Interface Plate, 148mm
  • 4 x M6 x 12 mm T20 screw
  • 1 x M4 x 12 mm T20 screw
  • 1 x Quick installation guide
Product Color: Signal White
Product Material: Aluminum
Product Type: Mounting Plate
$26.50

Shipping calculated at checkout

Regular price $26.50

View details

  • Call for availability

  • Call for availability


Pendant wall mount

NDA-U-WMT

  • Application/Usage: Wall,Indoor/Outdoor
  • Color Family: White
  • Compatibility: Bosch Cameras:
    • NDE-4502-ALAR Fixed dome Camera
    • NDI-4502-AAR Fixed Dome Camera
    • FLEXIDOME IP indoor 4000i
    • FLEXIDOME IP outdoor 4000i
    • FLEXIDOME IP indoor 5000i
    • FLEXIDOME IP outdoor 5000i
  • Country of Origin: Taiwan
View all specs
Application/Usage: Wall,Indoor/Outdoor
Color Family: White
Compatibility: Bosch Cameras:
  • NDE-4502-ALAR Fixed dome Camera
  • NDI-4502-AAR Fixed Dome Camera
  • FLEXIDOME IP indoor 4000i
  • FLEXIDOME IP outdoor 4000i
  • FLEXIDOME IP indoor 5000i
  • FLEXIDOME IP outdoor 5000i
Country of Origin: Taiwan
Device Supported: Network Camera
Diameter: 4"
Durability: Vibration Resistant,Shock Resistant,Impact Resistant,Weather Resistant,Vandal Resistant,Salt Resistant
Features: Swivel,IK10
Form Factor: Wall Mountable
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Package Contents:
  • 1 Wall mount
  • 4 M5 x 16mm pan head Torx screw with Zinc coating
  • 1 Thread seal tape: PTFE tape
  • 1 IP rubber plug
  • 1 T25 Torx key
  • 1 Quick Installation Guide
Product Color: White
Product Material: Aluminum Alloy
Product Type: Wall Mount
$54.40

Shipping calculated at checkout

Regular price $54.40

View details

  • Call for availability

  • Call for availability


Pole mount adapter large

NDA-U-PMAL

  • Application/Usage: Pole
  • Color Family: White
  • Compatibility: BOSCH - FLEXIDOME IP indoor 4000i
  • Country of Origin: China
View all specs
Application/Usage: Pole
Color Family: White
Compatibility: BOSCH - FLEXIDOME IP indoor 4000i
Country of Origin: China
Device Supported: Network Camera,Surveillance Cabinet
Durability: Weather Resistant
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Package Contents:
  • 1x Pole mount adapter large
  • 4 x 3/8 inch-16 x 1.75 inch Hex screw
  • 4 x 3/8 inch washer
  • 4 x M6 x 30 mm Hex screw
  • 4 x M6 washer
  • 4 x M6 spring washer
  • 2 x Strap, stainless
  • 5 x feet long
  • 2 x Buckle
  • 1 x Quick Installation Guide
Product Color: White
Product Material: Aluminum Alloy
Product Type: Mounting Adapter
$105

Shipping calculated at checkout

Regular price $105

View details

  • Call for availability

  • Call for availability


Wall mount plate

NDA-U-WMP

  • Application/Usage: Wall,Indoor/Outdoor
  • Color Family: White
  • Compatibility:

    Bosch AUTODOME IP 5000 HD Cameras

  • Country of Origin: China
View all specs
Application/Usage: Wall,Indoor/Outdoor
Color Family: White
Compatibility:

Bosch AUTODOME IP 5000 HD Cameras

Country of Origin: China
Device Supported: Surveillance Camera
Durability: Weather Proof,Weather Resistant,Vandal Resistant,Salt Resistant,Impact Resistant
Features: IK10
Form Factor: Wall Mountable
Ingress Protection (IP) Rating: IP66
Manufacturer: The Bosch Group
Manufacturer Website Address: http://www.bosch.com
Package Contents:
  • 1 x Wall Mount Plate
  • 1 x Quick Installation Guide
Product Color: White
Product Material: Aluminum Alloy
Product Type: Mounting Plate
$186

Shipping calculated at checkout

Regular price $186

View details

Showing 169-181 of 181 items

Looking for bulk order discounts and installation?

Contact us
Close (esc)

Subscribe to our monthly newsletter!

Stay up to date on what's happening in the tech world.

Age verification

By clicking enter you are verifying that you are old enough to consume alcohol.

Enter

Search

Header > Main Menu

Shopping Cart
