Panduit SmartZone U10S11V 10000VA Rack/Tower UPS
SKU: U10S11V
The Panduit® SmartZone™ UPS with maintenance free VRLA battery, 5-10kVA single phase 208 V and 230 V units is a pure Online Double Conversion system that delivers highly efficient and reliable power protection and power backup for your computer IT equipment. With excellent electrical performance, enhanced intelligent monitoring and network functions, complying with ENERGY STAR® 2.0, EMC and safety standards to meet the continually growing power demands of Data Center, Enterprise and Edge IT Infrastructure.
Call for Availability
Regular price
$6,770
Shipping calculated at checkout
The Panduit® SmartZone™ UPS with maintenance free VRLA battery, 5-10kVA single phase 208 V and 230 V units is a pure Online Double Conversion system that delivers highly efficient and reliable power protection and power backup for your computer IT equipment. With excellent electrical performance, enhanced intelligent monitoring and network functions, complying with ENERGY STAR® 2.0, EMC and safety standards to meet the continually growing power demands of Data Center, Enterprise and Edge IT Infrastructure.
Additional Warranty Information:
- 3 years for UPS & EBP
- 2 years for battery
Alarm:
UPS Alarm
Application/Usage:
Computer,IT Equipment,Data Center,Edge Computing
AVR:
Yes
Backup/Run Time (Full Load):
4.50 Minute
Backup/Run Time (Half Load):
12.90 Minute
Battery Capacity:
9000 mAh
Battery Characteristics:
Valve-regulated/Maintenance-free/Hot-swappable
Battery Size:
12V
DC System Voltage:
240 V DC
Energy Efficiency Certification:
ENERGY STAR 2.0
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
EPO Port:
Yes
Form Factor:
Rack/Tower
Input Frequency:
70 Hz
Input Voltage:
120 V AC,230 V AC
Input Voltage Range:
110 V AC - 285 V AC,185 V AC - 264 V AC
Limited Warranty:
3 Year
Load Capacity (VA):
10000 VA
Load Capacity (Watt):
10 kW
Manufacturer:
PANDUIT CORP
Manufacturer Website Address:
http://www.panduit.com
Maximum Operating Elevation:
9842.52 ft
Maximum Operating Temperature:
104°F (40°C)
Network Management:
SNMP/Webcard
Number of Batteries:
20
Output Frequency:
60 Hz
Output Voltage:
208 V AC,240 V AC
Overload Protection:
Yes
Packaged Quantity:
1 Pack
Phase:
Single Phase
Plug/Connector Type:
Hard Wire 3-wire (2PH + G)
Product Color:
Black
Product Line:
SmartZone
Product Model:
U10S11V
Product Type:
Double Conversion Online UPS
Rack Height:
6U
Receptacle Detail:
2 x NEMA L6-30R
Receptacle Type:
NEMA L6-30R
Replaceable Battery:
Yes
Serial Port:
Yes
Sound Emission:
58 dB
Status Indicators:
LED Indicators
Surge Energy Rating:
600 J
Thermal Dissipation:
581.75 W
Transfer Time:
0 ns
Typical Battery Recharge Time:
6 Hour
USB (HID Compliant) Port:
Yes
Waveform Type:
Pure Sine Wave
