ARCHIVED Server Technology Switched PDU - 3.3kW, C1W16HR-0AAA5BAC
SKU: C1W16HR-0AAA5BAC
The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- Provide circuit protection and easy configuration for trouble-free access
- With switched PDU, remotely monitor, connect or disconnect data center loads
- IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
- Three Phase phase PDU for reliable performance with maximum productivity
- IEC 60320 C20 plug/connector type for efficient connectivity and feasible power output
- 230 V AC input voltage for better reliance and maximum dependability
- 230 V AC output voltage for better reliance and maximum usability
Call for Availability
Regular price
$1,264
Shipping calculated at checkout
The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- Provide circuit protection and easy configuration for trouble-free access
- With switched PDU, remotely monitor, connect or disconnect data center loads
- IEC 60320 C13 receptacle type to ensure maximum productivity with added feasibility
- Three Phase phase PDU for reliable performance with maximum productivity
- IEC 60320 C20 plug/connector type for efficient connectivity and feasible power output
- 230 V AC input voltage for better reliance and maximum dependability
- 230 V AC output voltage for better reliance and maximum usability
Country of Origin:
United States
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Input Current:
16 A
Input Voltage:
230 V AC
Input Voltage Range:
120 V AC - 230 V AC
Management:
- SSH
- SMTP
- Syslog
- HTTP/HTTPS
- TLSv1.2
- SSHv2
- Telnet
- SNMPv2c and v3 (GET, SET, Traps)
- IPv4 and IPv6
- LDAPv3/LDAPS
- TACACS+
- RADIUS
- FTP/SFTP
Manufacturer:
Legrand Group
Manufacturer Website Address:
http://www.servertech.com
Mount Type:
Rack-mountable
Network (RJ-45):
Yes
Output Voltage:
230 V AC
PDU Type:
Switched
Phase:
Three Phase
Plug/Connector Type:
IEC 60320 C20
Power Rating (Watt):
3300 W
Product Model:
C1W16HR-0AAA5BAC
Product Series:
PRO1
Product Type:
PDU
Protection Type:
Fuse,Double Pole
Rack Height:
2U
Receptacle Detail:
16 x IEC 60320 C13
Receptacle Type:
IEC 60320 C13
