Vertiv Liebert GXT5 UPS 3kVA 208V L6-30P| Online Double Conversion Rack Mount/Tower | Energy Star Certified| Lead Acid| 1.0 PF (GXT5-3KL630RT2UXL)
SKU: GXT5-3KL630RT2UXL
The Vertiv Liebert GXT5-3KL630RT2UXL uninterruptible power supply (UPS) protects critical equipment against outages and power disturbances. This single-phase, 3kVA online double conversion UPS comes with an L6-30P Input Cord. It offers continuous power conditioning in centralized and edge locations. With a high power factor (0.9-1.0), it allows more connected loads, saving space and costs. This compact rack mount/tower UPS has an optional Vertiv RDU101 communications card for remote monitoring and control to help enable faster event resolution. With the free Vertiv Power Insight software, monitor up to 100 distributed UPS units and receive simple notifications of their status and events in one place. This UPS has scalable runtime options with matching external battery cabinets for extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive, gravity-sensing, full-color LCD screen.
- Vertiv Liebert GXT5-3KL630RT2UXL: 2U double conversion online UPS with L6-30P Input Cord
- High Power Factor (0.9-1.0) provides more usable power and more connected loads, saves space and costs
- Remote management and configuration of UPS with optional Vertiv RDU101 network communication card
- Energy Star 2.0 certified UPS helps reduce operation cost with high normal operating efficiency
- Compact tower/rack mount design with intuitive, gravity sensing, colored graphic LCD display
27 in stock
Regular price
$4,498.86
Sale price
$5,019
On Sale
Shipping calculated at checkout
The Vertiv Liebert GXT5-3KL630RT2UXL uninterruptible power supply (UPS) protects critical equipment against outages and power disturbances. This single-phase, 3kVA online double conversion UPS comes with an L6-30P Input Cord. It offers continuous power conditioning in centralized and edge locations. With a high power factor (0.9-1.0), it allows more connected loads, saving space and costs. This compact rack mount/tower UPS has an optional Vertiv RDU101 communications card for remote monitoring and control to help enable faster event resolution. With the free Vertiv Power Insight software, monitor up to 100 distributed UPS units and receive simple notifications of their status and events in one place. This UPS has scalable runtime options with matching external battery cabinets for extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive, gravity-sensing, full-color LCD screen.
- Vertiv Liebert GXT5-3KL630RT2UXL: 2U double conversion online UPS with L6-30P Input Cord
- High Power Factor (0.9-1.0) provides more usable power and more connected loads, saves space and costs
- Remote management and configuration of UPS with optional Vertiv RDU101 network communication card
- Energy Star 2.0 certified UPS helps reduce operation cost with high normal operating efficiency
- Compact tower/rack mount design with intuitive, gravity sensing, colored graphic LCD display
Additional Warranty Information:
Opt. 2 year extension
Application/Usage:
Mission Critical Equipment,Data Center
Backup/Run Time (Full Load):
3 Minute
Backup/Run Time (Half Load):
9 Minute
Backup/Run Time With External Battery Cabinet (Full Load):
17 Minute
Backup/Run Time With External Battery Cabinet (Half Load):
43.50 Minute
Battery Characteristics:
Valve-regulated, Non-spillable
Battery Chemistry:
Lead Acid
Cord Length:
10 ft
Country of Origin:
China
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS)
Environmental Sensors:
Leak Detection Sensor,Temperature Sensor,Humidity Sensor
Form Factor:
Rack/Tower
Hot Swappable:
Yes
Input Frequency:
50 Hz
Input Voltage:
208 V AC
Limited Warranty:
3 Year
Load Capacity (VA):
3000 VA
Load Capacity (Watt):
3000 W
Manufacturer:
Vertiv
Manufacturer Website Address:
http://www.vertiv.com/
Network (RJ-45):
Yes
Number of External Battery Cabinets:
1
Output Voltage:
200 V AC,208 V AC,220 V AC,230 V AC,240 V AC
Packaged Quantity:
1
Package Contents:
- GXT5 3kVA 208V UPS
- 4 Post Fixed Rail Kit
- Tower Stand
- USB Cable
- Quick Start Guide
- Safety Instruction Manual
Phase:
Single Phase
Plug/Connector Type:
NEMA L6-30P
Product Series:
GXT
Product Type:
Double Conversion Online UPS
Rack Height:
2U
Receptacle Detail:
2 x NEMA L6-30R,2 x NEMA L6-15R
Receptacle Type:
NEMA L6-30R,NEMA L6-15R
Serial Port:
Yes
Status Indicators:
Full Color Graphic LCD / Diagnostic LEDs:
- Alarm
- Fault Indication
TAA Compliant:
No
Transfer Time:
0 ns
USB:
Yes
Utility (AC) Mode Overload:
- >200% for 250ms
- 150-200% for 2 seconds
- 125-150% for 10 seconds
- 105-125% for 15 seconds
Waveform Type:
Sine Wave
