Vertiv Liebert EXS V-Model UPS tower 20kVA/20kW 208/120VAC (220/127VAC)3-phase 4 Wire|w/ Liebert Intellislot Card (SNMP)|RunTime 11min(EXSV-20KN)
SKU: EXSV-20KN
The Vertiv Liebert EXS V-Model (EXSV-20KN) is a compact monolithic uninterruptible power system (UPS) that employs true on-line, double-conversion technology that continuously conditions and regulates its output voltage. The Liebert EXS V-Model is designed to supply computers, servers, networking, and other sensitive equipment with clean sine wave input power. It is ideally suited to power IT devices in small data rooms, IT closets, VoIP, ISDN, storage, and security systems. It offers economical, efficient, and reliable three-phase power for critical loads up to 20kVA. This intelligent UPS has flexible UPS, power distribution and battery arrangements to meet capacity and runtime demands. It has an integrated maintenance bypass cabinet, which ensures critical loads operate even during service. It has unity power factor and high power-density in an optimized design and standalone unit. It is easy to install and operate.
- Reliable 3-phase power with double conversion technology for power protection and higher availability of critical systems
- High operating efficiency (>93% in double conversion mode, 99% in eco mode)
- Advanced battery monitoring
- Operational footprint and flexibility
- 1.0 Output Power Factor rating to deliver more usable power
Call for Availability
Regular price
$27,566.93
Sale price
$30,542
On Sale
Shipping calculated at checkout
The Vertiv Liebert EXS V-Model (EXSV-20KN) is a compact monolithic uninterruptible power system (UPS) that employs true on-line, double-conversion technology that continuously conditions and regulates its output voltage. The Liebert EXS V-Model is designed to supply computers, servers, networking, and other sensitive equipment with clean sine wave input power. It is ideally suited to power IT devices in small data rooms, IT closets, VoIP, ISDN, storage, and security systems. It offers economical, efficient, and reliable three-phase power for critical loads up to 20kVA. This intelligent UPS has flexible UPS, power distribution and battery arrangements to meet capacity and runtime demands. It has an integrated maintenance bypass cabinet, which ensures critical loads operate even during service. It has unity power factor and high power-density in an optimized design and standalone unit. It is easy to install and operate.
- Reliable 3-phase power with double conversion technology for power protection and higher availability of critical systems
- High operating efficiency (>93% in double conversion mode, 99% in eco mode)
- Advanced battery monitoring
- Operational footprint and flexibility
- 1.0 Output Power Factor rating to deliver more usable power
Application/Usage:
Data Center,IT,Server,Storage Device,IT System,Medical,Medical Equipment,VoIP,Security System,Banking,Retail,Healthcare,Manufacturing Facility
Backup/Run Time (Full Load):
11 Minute
Backup/Run Time (Half Load):
31 Minute
Battery Characteristics:
Valve-regulated
Battery Chemistry:
Lead Acid
Energy Efficiency Certification:
ENERGY STAR 2.0
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Environmental Sensors:
Humidity Sensor,Temperature Sensor
Form Factor:
Tower
Input Frequency:
60 Hz,40 Hz,70 Hz
Input Voltage:
120 V AC,230 V AC
Limited Warranty:
1 Year
Load Capacity (VA):
20 kVA
Load Capacity (Watt):
20 kW
Manufacturer:
Vertiv
Manufacturer Website Address:
http://www.vertiv.com/
Maximum Operating Elevation:
4921 ft
Maximum Operating Temperature:
104°F (40°C)
Network Management:
Intelligent Card Slot,Modbus RS-485,SNMP/Modbus/TCP/BacNet IP,Relay Contact
Output Frequency:
60 Hz
Output Power Factor:
1
Output Voltage:
208 V AC,120 V AC,220 V AC,127 V AC
Package Contents:
- EXSV-20KN 20kVA Tower UPS
- Quick Installation Guide
- Vertiv™ Power Insight Management Software (free download from Vertiv.com)
- IS-Unity DP Communication Card
- Safety Instructions
- WEE Recycling Sheet (ISO 14001 Compliance)
Phase:
Three Phase
Plug/Connector Type:
Hard Wire 4-wire (3PH + G)
Product Model:
EXSV-20KN
Product Series:
EXS
Product Type:
Double Conversion Online UPS
Receptacle Detail:
2 x Hard Wire 4-wire (3PH + G)
Receptacle Type:
Hard Wire 4-wire (3PH + G)
Software Included:
Vertiv Power Insight Management
