Schneider Electric Easy UPS On-Line Li-Ion SRVSL RT 1000VA 120V, with Rail Kit

SKU: SRVSL1KRARK

Single Phase True Double-conversion On-Line UPS Lithium-Ion battery has a lifetime of eight to ten years which offers reliable support and extends the useful life of your UPS. 120V 1000VA Standard built-in runtime model with rail kit More real output power in watts 0.9 PF Up to 90.69% efficiency in on-line double conversion mode and up to 95% in ECO mode saves utility and cooling costs without compromising performance or reliability. Its dimensions are 438mm (width) x 452mm (depth) x 86mm (height) 2U in total. The net weighs is 13kg. It's ideal for Building, Electrical Distribution companies, Machine Automation, System Integrators, Equipment Manufacturers, Technology and Solution Partners. cTUVus, NOM, RETIE, UN38.3 Managemnt Card (Network Management card, Dry contact card, modbus Card) and RBC options are available. Rack/ Tower convertible design with default accessory kit.

  • Offers power supply with zero transfer time taken to the battery and proves ideal for voltage sensitive equipments
  • Up to 10.58 minute runtime on full load to preserve critical data from power shortage interruptions
  • 900 W load capacity - backup power for your valuable electronics
  • 1000 VA load capacity provides sufficient backup during power failures
  • 38.4V battery size for better reliance and optimal performance
  • 2 Hour typical battery recharge time to allow uninterrupted usage without requiring power outlet
  • Lithium Ion (Li-Ion) battery chemistry to better suit your requirements with maximum productivity
  • NEMA 5-15P plug/connector type for maximum usability with added reliability
  • NEMA 5-15R receptacle type offers maximum safety, convenience, and increased usability
  • Single Phase phase for your convenience and optimal usage

Call for Availability

Regular price $2,693.01 Sale price $3,050
On Sale

Shipping calculated at checkout

Details

Single Phase True Double-conversion On-Line UPS Lithium-Ion battery has a lifetime of eight to ten years which offers reliable support and extends the useful life of your UPS. 120V 1000VA Standard built-in runtime model with rail kit More real output power in watts 0.9 PF Up to 90.69% efficiency in on-line double conversion mode and up to 95% in ECO mode saves utility and cooling costs without compromising performance or reliability. Its dimensions are 438mm (width) x 452mm (depth) x 86mm (height) 2U in total. The net weighs is 13kg. It's ideal for Building, Electrical Distribution companies, Machine Automation, System Integrators, Equipment Manufacturers, Technology and Solution Partners. cTUVus, NOM, RETIE, UN38.3 Managemnt Card (Network Management card, Dry contact card, modbus Card) and RBC options are available. Rack/ Tower convertible design with default accessory kit.

  • Offers power supply with zero transfer time taken to the battery and proves ideal for voltage sensitive equipments
  • Up to 10.58 minute runtime on full load to preserve critical data from power shortage interruptions
  • 900 W load capacity - backup power for your valuable electronics
  • 1000 VA load capacity provides sufficient backup during power failures
  • 38.4V battery size for better reliance and optimal performance
  • 2 Hour typical battery recharge time to allow uninterrupted usage without requiring power outlet
  • Lithium Ion (Li-Ion) battery chemistry to better suit your requirements with maximum productivity
  • NEMA 5-15P plug/connector type for maximum usability with added reliability
  • NEMA 5-15R receptacle type offers maximum safety, convenience, and increased usability
  • Single Phase phase for your convenience and optimal usage
Specifications
Application/Usage:
Building System,Distribution Center,Automation System,Manufacturing System
Backup/Run Time (Full Load):
10.58 Minute
Backup/Run Time (Half Load):
21.16 Minute
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Life:
10 Year
Battery Size:
38.4V
Display:
LCD
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE),China Restriction of Hazardous Substances (China RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
EPO Port:
Yes
Form Factor:
Rack/Tower
Input Frequency:
70 Hz
Input Voltage:
120 V AC
Input Voltage Range:
80 V AC - 150 V AC,55 V AC - 150 V AC
Limited Warranty:
3 Year
Load Capacity (VA):
1000 VA
Load Capacity (Watt):
900 W
Manufacturer:
Schneider Electric SA
Manufacturer Website Address:
http://www.schneider-electric.com
Maximum Operating Elevation:
9842.52 ft
Maximum Operating Temperature:
104°F (40°C)
Maximum Storage Elevation:
49212.60 ft
Output Frequency:
60 Hz
Output Voltage:
120 V AC,110 V AC,115 V AC
Packaged Quantity:
1
Package Contents:
  • Easy UPS On-Line Li-Ion SRVSL RT 1000VA 120V, with Rail Kit
  • Basic UPS Signalling RS-232 Cable
  • USB Cable
  • Rack Mounting Brackets
  • Rack Mounting Support Rails
  • Stabilization Feet
Phase:
Single Phase
Plug/Connector Type:
NEMA 5-15P
Product Color:
Black,Silver
Product Line:
Easy UPS On-Line
Product Series:
SRVSL RT
Product Type:
Double Conversion Online UPS
Rack Height:
2U
Receptacle Detail:
6 x NEMA 5-15R
Receptacle Type:
NEMA 5-15R
Serial Port:
Yes
Sound Emission (A-Weighted):
50 dB(A)
Storage Relative Humidity:
0% - 95%
Storage Temperature:
-4°F (-20°C) - 122°F (50°C)
Surge Energy Rating:
220 J
Typical Battery Recharge Time:
2 Hour
USB:
Yes
Waveform Type:
Sine Wave
