Tycon Power (TP-DCDC-1248D) 9-36VDC In, 48VDC 802.3af Out 17W DCDC Conv/POE
SKU: TP-DCDC-1248D
802.3af Compatible. Will only power up when connected to an 802.3af device.
The TP-DCDC-1248D DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a 12 or 24V battery system.
They have an integrated POE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 9VDC and 36VDC.
They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack.
They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-).
They have various protections for surge, short circuit and overload. The units have power output of 24W.
The TP-DCDC-1248D DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a 12 or 24V battery system.
They have an integrated POE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 9VDC and 36VDC.
They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack.
They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-).
They have various protections for surge, short circuit and overload. The units have power output of 24W.
Call for Availability
Regular price
$68.95
Shipping calculated at checkout
802.3af Compatible. Will only power up when connected to an 802.3af device.
The TP-DCDC-1248D DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a 12 or 24V battery system.
They have an integrated POE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 9VDC and 36VDC.
They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack.
They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-).
They have various protections for surge, short circuit and overload. The units have power output of 24W.
The TP-DCDC-1248D DC to DC converters offered by Tycon Power Systems are a low cost and high reliability solution for those requiring 48VDC Power Over Ethernet voltage from a 12 or 24V battery system.
They have an integrated POE injector to apply the regulated 48VDC to the CAT5 Ethernet cable. The input voltage must be between 9VDC and 36VDC.
They accept data-in to a shielded RJ45 Jack and provide data-out and POE power on the shielded RJ45 output jack.
They work by supplying power on the unused Ethernet pins 4,5(V+) and 7,8(V-).
They have various protections for surge, short circuit and overload. The units have power output of 24W.
Certifications & Standards:
- IEEE 802.3af
- FCC Class B
- NE55022 Class B
- UL1950
- CSA 22.2
- TUV
- EN60950
- EN61000-4
Compatibility:
- Wireless Access Points
- IP Phones
- Security Cameras
Input Ports:
1 x 10/100Base-TX
Input Voltage:
12 V DC,24 V DC
Limited Warranty:
1 Year
Manufacturer:
Tycon Power Systems
Manufacturer Website Address:
http://www.tyconpower.com
Maximum Output Current:
350 mA
Maximum Output Power:
17 W
Maximum Output Voltage:
48 V DC
Output Ports:
1 x 10/100Base-TX
Product Model:
TP-DCDC-1248D
Product Type:
PoE Injector
