Tycon Power PoE Injector
Description
The TP-POE-1824 is a unique Power Over Ethernet adapter which converts an 802.3af/at 48VDC POE input into a 18V or 24VDC regulated passive POE output. The POE output voltage is external jumper selectable and capable of up to 25W power output. The POE input is IEEE 802.3af/at compatible so the TP-POE-1824 will work with standard 802.3af/at compliant POE switches or routers. The TP-POE-1824 enables the powering of passive POE devices from standard 802.3af/at POE switches, which eliminates the extra expenses usually required to power non compliant equipment.
There are two models available:
TP-POE-1824 which is 10/100MB compatible and has a 12W output.
TP-POE-1824G which is 10/100/1000MB compatible and has a 24W output.
They accept data-in and 802.3af/at POE to a shielded RJ45 Jack and provide data-out and 18V or 24V POE on the shielded RJ45 output jack. They workby supplying power to the remote device on the unused Ethernet pins 4,5(V+) and 7,8(V-). The Ethernet spec supports distances up to 100m (328 feet).
They have various protections for surge, short circuit, overload and overvoltage.
Call for Availability
Shipping calculated at checkout
Description
The TP-POE-1824 is a unique Power Over Ethernet adapter which converts an 802.3af/at 48VDC POE input into a 18V or 24VDC regulated passive POE output. The POE output voltage is external jumper selectable and capable of up to 25W power output. The POE input is IEEE 802.3af/at compatible so the TP-POE-1824 will work with standard 802.3af/at compliant POE switches or routers. The TP-POE-1824 enables the powering of passive POE devices from standard 802.3af/at POE switches, which eliminates the extra expenses usually required to power non compliant equipment.
There are two models available:
TP-POE-1824 which is 10/100MB compatible and has a 12W output.
TP-POE-1824G which is 10/100/1000MB compatible and has a 24W output.
They accept data-in and 802.3af/at POE to a shielded RJ45 Jack and provide data-out and 18V or 24V POE on the shielded RJ45 output jack. They workby supplying power to the remote device on the unused Ethernet pins 4,5(V+) and 7,8(V-). The Ethernet spec supports distances up to 100m (328 feet).
They have various protections for surge, short circuit, overload and overvoltage.
- FCC Class B
- NE55022 Class B
- UL1950
- CSA 22.2
- TUV EN60950
- Wireless Access Points
- Client Devices
- IP Phone
- Security Camera Systems
