Vertiv Geist Rack Transfer Switch PDU with Next-Generation IMD| 15A| 120V| 1.4kW| (10) NEMA 5-15R Receptacles| (2) NEMA 5-15P Plug| VA4N11A0

SKU: VA4N11A0
The Vertiv Geist Rack Transfer Switch VA4N11A0 is a 15A, 120V, single phase unit level monitored rPDU with (10) NEMA 5-15R Receptacles and (2) NEMA 5-15P plug that provides 1.4kW of power capacity. This unit provides backup power to single-corded devices and helps ensure continuity in the event of power loss. It quickly detects power loss on the main source and automatically switches to the secondary source within less than 4 to 8 milliseconds. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.

More from the Manufacturer

  • Vertiv Geist Rack Transfer Switch gives backup power to single corded devices in case of power loss
  • VA4N11A0 is a 15A, 120V, rPDU with 1.4kW power capacity and (10) NEMA 5-15R Receptacles
  • Vertiv Geist Next-Generation IMD has a 128x128 high-contrast LCD for monitoring data
  • Helps ensure that data and operations are protected with the enhanced security features
  • Vertiv Geist rPDUs are individually tested, UL-Listed, TAA-Compliant, and RoHS certified

Call for Availability

Regular price $2,180

Shipping calculated at checkout

Details
The Vertiv Geist Rack Transfer Switch VA4N11A0 is a 15A, 120V, single phase unit level monitored rPDU with (10) NEMA 5-15R Receptacles and (2) NEMA 5-15P plug that provides 1.4kW of power capacity. This unit provides backup power to single-corded devices and helps ensure continuity in the event of power loss. It quickly detects power loss on the main source and automatically switches to the secondary source within less than 4 to 8 milliseconds. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.

More from the Manufacturer

  • Vertiv Geist Rack Transfer Switch gives backup power to single corded devices in case of power loss
  • VA4N11A0 is a 15A, 120V, rPDU with 1.4kW power capacity and (10) NEMA 5-15R Receptacles
  • Vertiv Geist Next-Generation IMD has a 128x128 high-contrast LCD for monitoring data
  • Helps ensure that data and operations are protected with the enhanced security features
  • Vertiv Geist rPDUs are individually tested, UL-Listed, TAA-Compliant, and RoHS certified
Specifications
Additional Warranty Information:
5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
Cord Length:
20 ft
Country of Origin:
United States
Environmentally Friendly:
Yes
Environmental Compliance:
China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS)
Features:
LCD Display,Touch Screen Display
Form Factor:
Rack
Input Current:
15 A
Input Voltage:
120 V AC
Input Voltage Range:
100 V AC - 120 V AC
Limited Warranty:
5 Year
Load Capacity (Watt):
1400 W
Management:
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Modbus TCP/IP
  • Syslog
  • TACACS+
  • Manufacturer:
    Vertiv
    Manufacturer Website Address:
    http://www.vertiv.com/
    Mounting Orientation:
    Horizontal
    Mount Type:
    Rack-mountable
    Network (RJ-45):
    Yes
    Output Voltage Range:
    100 V AC - 120 V AC
    PDU Type:
    Monitored
    Phase:
    Single Phase
    Plug/Connector Detail:
    2 x NEMA 5-15P
    Plug/Connector Type:
    NEMA 5-15P
    Power Rating (Watt):
    1400 W
    Product Color:
    Black
    Product Line:
    Geist Upgradeable
    Product Model:
    AN03E1R5-10S153-1ST5ST5A011-D
    Product Series:
    N
    Product Type:
    PDU
    Rack Height:
    1U
    Receptacle Detail:
    10 x NEMA 5-15R
    Receptacle Type:
    NEMA 5-15R
    Remote Outlet Switching:
    No
    TAA Compliant:
    Yes
