Opticon OPL-9815 Mobile Data Collector
Bluetooth Laser Barcode Scanner with GPS, Screen, and 18-key Operation
The OPL-9815, a Bluetooth™ laser scanner from Opticon, features GPS, a real-time clock and 18-key operation for data-capture applications that require location and time stamps, as well as data entry. The OPL-9815 is perfect for inventory, logistics, warehouse and retail applications. Since the OPL-9815 is programmable, channel partners can create custom solutions around the OPL-9815 using the free SDK from Opticon.
The OPL-9815 can transmit data via Bluetooth™ connection, or store data onboard for later transfer via IrDA through a charging cradle (sold separately). The charging cradle is available with a serial, modem or GSM interface. OPL-9815 product highlights include:
- Wireless laser barcode scanner with GPS - featuring 100 scans per second speed
- HID or SPP Bluetooth™ transmission of data to a host
- 512KB of flash ROM and 512KB of RAM
- 18-key operation
- Monochrome 112x64 pixel screen with back light
- Programmable - free Opticon SDK enables solution providers to create customized scanning solutions
- Compact size and weight - 1.7"W x 5.5"L x 0.9"D; 3.8 oz
- Rechargeable Lithium-Ion battery
- Minimum standby time is 48 hours
- IP54 enclosure rating; withstands 5-foot drop to concrete
- Data can also be transmitted to host via IrDA when OPL-9815 is placed in charging cradle
- Two-year warranty
- Ideal solution for asset management, inventory control and mobile sales automation
- Features 100 scans/second high speed laser barcode scanner
- Wireless Bluetooth (HID or SPP) transmission of data to a host
- Data can also be transferred via USB, RS232 and GSM thought the various communication/charging cradles that are sold separately
- Integrated GPS and real time clock for mobile applications that require location coordinates and time stamps
- 18-key keypad and monochrome 112x64 pixel LCD screen with backlight
- Memory: 512KB of flash ROM and 1MB of RAM
- Compact size and weight: 1.7" x 5.5" x 0.9" (WxLxD), 3.8 ounces
- Rechargeable Lithium-Ion battery
- Rugged: IP54 rating against dust and moisture, survives 5 foot drops to concrete
- Programmable - free Opticon SDK enables solution providers to create customized scanning solutions
- Two year warranty
Call for Availability
Shipping calculated at checkout
Bluetooth Laser Barcode Scanner with GPS, Screen, and 18-key Operation
The OPL-9815, a Bluetooth™ laser scanner from Opticon, features GPS, a real-time clock and 18-key operation for data-capture applications that require location and time stamps, as well as data entry. The OPL-9815 is perfect for inventory, logistics, warehouse and retail applications. Since the OPL-9815 is programmable, channel partners can create custom solutions around the OPL-9815 using the free SDK from Opticon.
The OPL-9815 can transmit data via Bluetooth™ connection, or store data onboard for later transfer via IrDA through a charging cradle (sold separately). The charging cradle is available with a serial, modem or GSM interface. OPL-9815 product highlights include:
- Wireless laser barcode scanner with GPS - featuring 100 scans per second speed
- HID or SPP Bluetooth™ transmission of data to a host
- 512KB of flash ROM and 512KB of RAM
- 18-key operation
- Monochrome 112x64 pixel screen with back light
- Programmable - free Opticon SDK enables solution providers to create customized scanning solutions
- Compact size and weight - 1.7"W x 5.5"L x 0.9"D; 3.8 oz
- Rechargeable Lithium-Ion battery
- Minimum standby time is 48 hours
- IP54 enclosure rating; withstands 5-foot drop to concrete
- Data can also be transmitted to host via IrDA when OPL-9815 is placed in charging cradle
- Two-year warranty
- Ideal solution for asset management, inventory control and mobile sales automation
- Features 100 scans/second high speed laser barcode scanner
- Wireless Bluetooth (HID or SPP) transmission of data to a host
- Data can also be transferred via USB, RS232 and GSM thought the various communication/charging cradles that are sold separately
- Integrated GPS and real time clock for mobile applications that require location coordinates and time stamps
- 18-key keypad and monochrome 112x64 pixel LCD screen with backlight
- Memory: 512KB of flash ROM and 1MB of RAM
- Compact size and weight: 1.7" x 5.5" x 0.9" (WxLxD), 3.8 ounces
- Rechargeable Lithium-Ion battery
- Rugged: IP54 rating against dust and moisture, survives 5 foot drops to concrete
- Programmable - free Opticon SDK enables solution providers to create customized scanning solutions
- Two year warranty
1D:
- JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN -128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal Codes:
- Chinese Post, Korean Postal Authority code
5 ft (1.5 m) drop onto concrete surface
