Marshall - 5 mmf/2 - Fixed Lens for CS Mount
SKU: V-555.0-5MP-VIS-IR 1/2
Marshall - 5 mmf/2 - Fixed Lens for CS Mount - Designed for Surveillance Camera - 1" Length - 1.1" Diameter
- 3.9mm, 5.0mm, 7.6mm focal lengths Visible - IR Corrected performance
- 5MP 1/2 sensor optical design
- High performance 5MP image quality in visible to near zero light; broadcast, OEM, machine vision, security, med process applications
- High performance Broadcast quality imaging
- High performance MTF > 70% at center field; > 63% at full field
- New compact mechanical, smooth tactile adjustment CS-Mount housing
- M12 Mount / S-Mount / CS-Mount models
- Glass optics
- Anodized aluminum housing
- RoHS compliant
Call for Availability
Regular price
$89.50
Shipping calculated at checkout
Marshall - 5 mmf/2 - Fixed Lens for CS Mount - Designed for Surveillance Camera - 1" Length - 1.1" Diameter
- 3.9mm, 5.0mm, 7.6mm focal lengths Visible - IR Corrected performance
- 5MP 1/2 sensor optical design
- High performance 5MP image quality in visible to near zero light; broadcast, OEM, machine vision, security, med process applications
- High performance Broadcast quality imaging
- High performance MTF > 70% at center field; > 63% at full field
- New compact mechanical, smooth tactile adjustment CS-Mount housing
- M12 Mount / S-Mount / CS-Mount models
- Glass optics
- Anodized aluminum housing
- RoHS compliant
Application/Usage:
Surveillance Camera
Autofocus:
No
Diameter:
1.1"
Environmentally Friendly:
Yes
Field of View:
1/2" Sensor Diagonal: 99.4°, Horizontal: 75.5°, Vertical: 55.1°, 1/2.5" Sensor Diagonal: 88.9° Horizontal: 75.5°, Vertical: 40.7°
Iris Type:
Fixed
Length:
1"
Lens Mount Type:
CS Mount
Lens Type:
Fixed
Manufacturer:
Marshall Electronics, Inc
Manufacturer Website Address:
http://www.mars-cam.com
Maximum Aperture:
f/2
Maximum Focal Length:
5 mm
Product Series:
5500
Product Type:
Lens
Sensor Size Compatibility:
1/2",1/2.5"
