Lenovo ThinkSystem SR630 V2 7Z71A061NA 1U Rack Server - Serial ATA/600, 12Gb/s SAS Controller

SKU: 7Z71A061NA

The Lenovo ThinkSystem SR630 V2 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

  • TruDDR4 memory technology effectively enables data to be moved at various points in a CPU clock cycle to allow maximum productivity
  • 2 processors supported for enhanced, dependable system performance with maximum usability
  • RAID provides efficient data redundancy in the case of a drive failure to ensure maximum dependability
  • 6 USB ports allows quick transmission of data at a higher rate for your convenience
  • 1 Network (RJ-45) Ports conveniently allows system integration and network installers to organize powered devices in locations that lack electrical circuitry
  • Gigabit Ethernet is very useful when a large number of file transfers are required such as when performing backups over the network
  • Rack form factor for added reliability and dependability

Call for Availability

Regular price $4,485.29

Shipping calculated at checkout

Details

The Lenovo ThinkSystem SR630 V2 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

  • TruDDR4 memory technology effectively enables data to be moved at various points in a CPU clock cycle to allow maximum productivity
  • 2 processors supported for enhanced, dependable system performance with maximum usability
  • RAID provides efficient data redundancy in the case of a drive failure to ensure maximum dependability
  • 6 USB ports allows quick transmission of data at a higher rate for your convenience
  • 1 Network (RJ-45) Ports conveniently allows system integration and network installers to organize powered devices in locations that lack electrical circuitry
  • Gigabit Ethernet is very useful when a large number of file transfers are required such as when performing backups over the network
  • Rack form factor for added reliability and dependability
Specifications
Chipset Manufacturer:
Intel
Chipset Model:
C621A
Controller Model:
Intel RSTe RAID
Controller Type:
Serial ATA/600,12Gb/s SAS
Energy Efficiency Certification:
ENERGY STAR 3.0,China Energy Conservation Program (CECP)
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Error Checking:
ECC
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Rack
Graphics Controller Model:
G200
Graphics Memory Capacity:
16 MB
Input Voltage:
120 V AC,230 V AC
Intel Optane Memory Ready:
Yes
Limited Warranty:
3 Year
Manufacturer:
Lenovo Group Limited
Manufacturer Website Address:
http://www.lenovo.com/us/en/
Maximum Memory Supported:
8 TB
Memory Clock Speed:
3.20 GHz
Memory Technology:
TruDDR4
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
1
Number of Power Supplies Supported:
2
Number of Processors Supported:
2
Number of USB 2.0 Ports:
1
Operating System Supported:
Windows Server 2016,Windows Server 2019,Windows Server 2022,Red Hat Enterprise Linux 7.9,Red Hat Enterprise Linux 8.2,Red Hat Enterprise Linux 8.3,Red Hat Enterprise Linux 8.4,Red Hat Enterprise Linux 8.5,SUSE Linux Enterprise Server 12 SP5,SUSE Linux Enterprise Server 15 SP2,SUSE Linux Enterprise Server 15 SP3
Product Line:
ThinkSystem
Product Model:
7Z71A061NA
Product Series:
SR630 V2
Product Type:
Server
Rack Height:
1U
RAID Levels:
0, 1, 5, 10, JBOD
RAID Supported:
Yes
Remote Management:
Yes
Remote Management Controller:
XClarity Controller (XCC) Enterprise
Security Features:
  • Chassis Intrusion Switch
  • Power-on Password
  • Administrator's Password
  • Trusted Platform Module (TPM), supporting TPM 2.0
Total Number of Memory Slots:
32
Total Number of USB Ports:
6
VGA:
Yes
