Shuttle XPC slim DH670 Barebone System - Slim PC - Socket LGA-1700 - 1 x Processor Support
SKU: DH670
ROBUST 1.3-LITRE SLIMPC SUPPORTS INTEL CORE GEN. 12 PROCESSORS "ALDER LAKE-S" AND FOUR UHD DISPLAYS
The Shuttle XPC slim Barebone DH670 with H670 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH670 allows for four Ultra HD displays to be operated at the same time via 2x HDMI and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
The Shuttle XPC slim Barebone DH670 with H670 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH670 allows for four Ultra HD displays to be operated at the same time via 2x HDMI and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
- Experience responsive performance, power, adaptability and fun with Intel Celeron processor
- DDR4 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Featuring 8 USB ports to connect USB-compatible devices
- With Serial ATA/600 interface get superb reliability and high-speed data transfer
Call for Availability
Regular price
$519.99
Shipping calculated at checkout
ROBUST 1.3-LITRE SLIMPC SUPPORTS INTEL CORE GEN. 12 PROCESSORS "ALDER LAKE-S" AND FOUR UHD DISPLAYS
The Shuttle XPC slim Barebone DH670 with H670 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH670 allows for four Ultra HD displays to be operated at the same time via 2x HDMI and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
The Shuttle XPC slim Barebone DH670 with H670 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH670 allows for four Ultra HD displays to be operated at the same time via 2x HDMI and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
- Experience responsive performance, power, adaptability and fun with Intel Celeron processor
- DDR4 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Featuring 8 USB ports to connect USB-compatible devices
- With Serial ATA/600 interface get superb reliability and high-speed data transfer
64-bit Processing:
Yes
Chipset Manufacturer:
Intel
Chipset Model:
H670
Color Family:
Black
Controller Type:
Serial ATA/600
Energy Efficiency Compliance:
Energy-related Products Directive (ErP)
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Slim PC
Graphics Controller Model:
HD Graphics
Graphics Memory Accessibility:
Shared
Graphics Memory Technology:
DDR4 SDRAM
HDMI (Rear):
Yes
Input Voltage:
120 V AC,230 V AC
Limited Warranty:
3 Year
Manufacturer:
Shuttle, Inc
Manufacturer Website Address:
http://www.us.shuttle.com
Maximum Memory Supported:
64 GB
Maximum Power Supply Wattage:
120 W
Memory Standard:
DDR4-3200/PC4-25600
Memory Technology:
DDR4 SDRAM
Number of Power Supplies Installed:
1
Number of Processors Supported:
1
Number of Total Expansion Bays:
1
Number of USB 3.2 Gen 1 Ports:
3
Number of USB 3.2 Gen 2 Ports:
4
Operating System Supported:
Windows 10 x64,Windows 11 x64,Linux
Package Contents:
- XPC slim DH670 Barebone System
- Power Adapter
- Quick Guide
- Screw Package
- Power Cord
- Driver DVD
- VESA Mount
- VESA Mount Quick Guide
- Thermal Grease
- HDD Screw Pack
Processor Socket:
Socket LGA-1700
Processor Supported:
Core i3,Core i5,Core i7,Core i9,Celeron,Pentium Gold
Product Color:
Black
Product Line:
XPC slim
Product Model:
DH670
Product Series:
DH6xx
Product Type:
Barebone System
Total Number of Expansion Slots:
2
Total Number of Memory Slots:
2
Total Number of USB Ports:
8
USB Type-C (Front):
Yes
USB Type-C Detail:
USB 3.2 Gen 1 (Type-C x 1)
