Asus RS720Q-E7/RS12 Barebone System - 2U Rack-mountable - Socket R LGA-2011 - 2 x Processor Support

SKU: RS720Q-E7/RS12
High Density Computing for HPC Applications

Based on the Intel® Socket R E5-2600 processor platform, the latest ASUS flagship server offers customers four individual nodes in a 2U space, with 16 DIMM slots supporting up to 512GB R-DIMM memory per node. Features include high efficiency 1+1 1620W 80+ Platinum power supplies, a fully modular design, hot-swap functionality, remote management, and high reliability, making the RS720Q-E7/RS12 an ideal choice for HPC, could computing, data center, and virtualization applications.

  • Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
  • DDR3 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
  • Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
  • Connect USB-enabled devices via 3 USB ports
  • With Serial ATA/600 interface get superb reliability and high-speed data transfer

Call for Availability

Regular price $2,828.17

Shipping calculated at checkout

Details
High Density Computing for HPC Applications

Based on the Intel® Socket R E5-2600 processor platform, the latest ASUS flagship server offers customers four individual nodes in a 2U space, with 16 DIMM slots supporting up to 512GB R-DIMM memory per node. Features include high efficiency 1+1 1620W 80+ Platinum power supplies, a fully modular design, hot-swap functionality, remote management, and high reliability, making the RS720Q-E7/RS12 an ideal choice for HPC, could computing, data center, and virtualization applications.

  • Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
  • DDR3 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
  • Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
  • Connect USB-enabled devices via 3 USB ports
  • With Serial ATA/600 interface get superb reliability and high-speed data transfer
Specifications
Chipset Manufacturer:
Intel
Chipset Model:
C602-A
Controller Type:
Serial ATA/600
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Rack-mountable
Graphics Controller Model:
AST2300
Graphics Memory Capacity:
16 MB
Input Voltage:
220 V AC
Limited Warranty:
3 Year
Manufacturer:
ASUS Computer International
Manufacturer Website Address:
http://usa.asus.com
Maximum Memory Supported:
512 GB
Maximum Power Supply Wattage:
1620 W
Memory Standard:
DDR3-1600/PC3-12800
Memory Technology:
DDR3 SDRAM
Network (RJ-45):
Yes
Number of 3.5" Bays:
3
Number of Nodes:
4
Number of PCI Express x16 Slots:
1
Number of Power Supplies Installed:
2
Number of Processors Supported:
2
Number of SATA Interfaces:
4
Number of Total Expansion Bays:
3
Operating System Supported:
Windows Server 2008 R2 Standard,Windows Server 2008 Enterprise Edition,Windows Server 2008 Enterprise x64 Edition,Red Hat Enterprise Linux AS5.6,Red Hat Enterprise Linux AS5.6 x64,Red Hat Enterprise Linux AS6,Red Hat Enterprise Linux AS6 x64,SuSE Linux Enterprise Server 11.2,SuSE Linux Enterprise Server 11.2 x64
Package Contents:
  • RS720Q-E7/RS12 Barebone System
  • 1 x Bag of Screws
  • 2 x AC Power Cable
  • 1 x Infiniband Support DVD
  • 1 x RS72xQ-E7 Support DVD
  • 1 x RS72xQ-E7 User's Guide
  • 1 x ASWM ENTERPRISE DVD
  • 1 x ASUS ASWM Enterprise User's Guide
  • 1 x ASMB6-iKVM SDVD
  • 1 x ASWM6-iKVM User Guide
Processor Socket:
Socket R LGA-2011
Processor Supported:
Xeon
Product Model:
RS720Q-E7/RS12
Product Type:
Barebone System
Rack Height:
2U
RAID Levels:
0, 1, 5
RAID Supported:
Yes
Total Number of Expansion Slots:
1
Total Number of Memory Slots:
16
Total Number of USB Ports:
3
