ASRock Rack 1U2E-X570 Barebone System - 1U Rack-mountable - Socket AM4 - 1 x Processor Support
SKU: 1U2E-X570
ASRock Rack 1U2E-X570 Barebone System - 1U Rack-mountable - Socket AM4 - 1 x Processor Support - AMD X570 Chip - 32 GB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 4 Total Memory Slots - Serial ATA/600 RAID Supported, NVMe Controller - AST2500 Graphic(s) - 1 3.5" Bay(s) - Network (RJ-45) - 2 M.2 Interface(s) - Processor Support (Ryzen) - Gigabit Ethernet - 2 USB 3.0 Port(s) - 1 x 315 W
- 1U Rackmount with 1, 80-PLUS Gold, 315W PSU
- Supports AMD Ryzen 5000 Series Desktop Processors
- 4 DIMM slots (2DPC), supports DDR4 ECC/ non-ECC UDIMM
- 2 Hot-swap 2.5'' NVMe (PCIe4.0 x4)/SATA drive bays
- 1 fixed 3.5'' SATA drive bay or 1 Slim ODD
- Supports 2 M.2 (PCIe4.0 x4 or SATA 6Gb/s)
- 2 RJ45 (1GbE) by Intel®i210
- VGA, HDMI
- Remote Management (IPMI)
Call for Availability
Regular price
$951.31
Shipping calculated at checkout
ASRock Rack 1U2E-X570 Barebone System - 1U Rack-mountable - Socket AM4 - 1 x Processor Support - AMD X570 Chip - 32 GB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 4 Total Memory Slots - Serial ATA/600 RAID Supported, NVMe Controller - AST2500 Graphic(s) - 1 3.5" Bay(s) - Network (RJ-45) - 2 M.2 Interface(s) - Processor Support (Ryzen) - Gigabit Ethernet - 2 USB 3.0 Port(s) - 1 x 315 W
- 1U Rackmount with 1, 80-PLUS Gold, 315W PSU
- Supports AMD Ryzen 5000 Series Desktop Processors
- 4 DIMM slots (2DPC), supports DDR4 ECC/ non-ECC UDIMM
- 2 Hot-swap 2.5'' NVMe (PCIe4.0 x4)/SATA drive bays
- 1 fixed 3.5'' SATA drive bay or 1 Slim ODD
- Supports 2 M.2 (PCIe4.0 x4 or SATA 6Gb/s)
- 2 RJ45 (1GbE) by Intel®i210
- VGA, HDMI
- Remote Management (IPMI)
64-bit Processing:
Yes
Chipset Manufacturer:
AMD
Chipset Model:
X570
Controller Type:
Serial ATA/600,NVMe
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Rack-mountable
Graphics Controller Model:
AST2500
Graphics Memory Accessibility:
Shared
Graphics Memory Technology:
DDR4 SDRAM
HDMI (Rear):
Yes
Manufacturer:
ASRock Rack Inc
Manufacturer Website Address:
https://www.asrockrack.com/index.asp
Maximum Memory Supported:
32 GB
Maximum Power Supply Wattage:
315 W
Memory Standard:
DDR4-3200/PC4-25600
Memory Technology:
DDR4 SDRAM
Network (RJ-45):
Yes
Number of 3.5" Bays:
1
Number of M.2 Interfaces:
2
Number of Network (RJ-45) Ports:
4
Number of Power Supplies Installed:
1
Number of Processors Supported:
1
Number of Serial Ports:
1
Number of Total Expansion Bays:
3
Number of USB 3.0 Ports:
2
Number of USB 3.2 Gen 2 Ports:
2
Number of VGA Ports:
1
Processor Socket:
Socket AM4
Processor Supported:
Ryzen
Product Model:
1U2E-X570
Product Type:
Barebone System
Rack Height:
1U
RAID Supported:
Yes
Total Number of Expansion Slots:
2
Total Number of Memory Slots:
4
Total Number of USB Ports:
4
