1U2S-B650 Barebone System - 1U Rack-mountable - Socket AM5 - 1 x Processor Support
SKU: 1U2S-B650
1U2S-B650 Barebone System - 1U Rack-mountable - Socket AM5 - 1 x Processor Support - AMD B650 Chip - 48 GB DDR5 SDRAM DDR5-5200/PC5-41600 Maximum RAM Support - 4 Total Memory Slots - Serial ATA Controller - AST2600 Graphic(s) - 1 3.5" Bay(s) - HDMI - DisplayPort - Network (RJ-45) - 2 M.2 Interface(s) - Processor Support (Ryzen, EPYC) - Gigabit Ethernet - 6 USB 3.2 Gen 1 Port(s) - 1 x 315 W
- 1U Rackmount with 1, 80-PLUS Gold, 315W PSU
- Single Socket AM5 (LGA 1718), supports AMD EPYC™ 4004 and AMD Ryzen™ 9000/8000/7000 Series Processors
- 4 DIMM slots (2DPC), supports DDR5 ECC/non-ECC UDIMM
- 2 hot-swap 2.5" SATA drive bays
- 1 fixed 3.5" SATA drive bay or 1 Slim ODD
- 1 FHHL PCIe4.0 x16
- Supports 1 M.2 (PCIe5.0 x4), 1 M.2 (PCIe4.0 x4)
- 2 RJ45 (1GbE) by Intel®i210
- 1 HDMI, 1 DisplayPort
- Remote Management (IPMI)
Call for Availability
Regular price
$906.20
Shipping calculated at checkout
1U2S-B650 Barebone System - 1U Rack-mountable - Socket AM5 - 1 x Processor Support - AMD B650 Chip - 48 GB DDR5 SDRAM DDR5-5200/PC5-41600 Maximum RAM Support - 4 Total Memory Slots - Serial ATA Controller - AST2600 Graphic(s) - 1 3.5" Bay(s) - HDMI - DisplayPort - Network (RJ-45) - 2 M.2 Interface(s) - Processor Support (Ryzen, EPYC) - Gigabit Ethernet - 6 USB 3.2 Gen 1 Port(s) - 1 x 315 W
- 1U Rackmount with 1, 80-PLUS Gold, 315W PSU
- Single Socket AM5 (LGA 1718), supports AMD EPYC™ 4004 and AMD Ryzen™ 9000/8000/7000 Series Processors
- 4 DIMM slots (2DPC), supports DDR5 ECC/non-ECC UDIMM
- 2 hot-swap 2.5" SATA drive bays
- 1 fixed 3.5" SATA drive bay or 1 Slim ODD
- 1 FHHL PCIe4.0 x16
- Supports 1 M.2 (PCIe5.0 x4), 1 M.2 (PCIe4.0 x4)
- 2 RJ45 (1GbE) by Intel®i210
- 1 HDMI, 1 DisplayPort
- Remote Management (IPMI)
64-bit Processing:
Yes
Chipset Manufacturer:
AMD
Chipset Model:
B650
Controller Type:
Serial ATA
DisplayPort:
Yes
Ethernet Technology:
Gigabit Ethernet
Form Factor:
Rack-mountable
Graphics Controller Model:
AST2600
HDMI:
Yes
Manufacturer Website Address:
https://www.asrockrack.com/index.asp
Maximum Memory Supported:
48 GB
Maximum Power Supply Wattage:
315 W
Memory Standard:
DDR5-5200/PC5-41600
Memory Technology:
DDR5 SDRAM
Network (RJ-45):
Yes
Number of 3.5" Bays:
1
Number of M.2 Interfaces:
2
Number of Network (RJ-45) Ports:
5
Number of PCI Express x16 Slots:
1
Number of Power Supplies Installed:
1
Number of Processors Supported:
1
Number of Serial Ports:
1
Number of Total Expansion Bays:
3
Number of USB 3.2 Gen 1 Ports:
6
Number of VGA Ports:
1
Processor Socket:
Socket AM5
Processor Supported:
Ryzen,EPYC
Product Model:
1U2S-B650
Product Type:
Barebone System
Rack Height:
1U
Thermal Design Power:
120 W
Total Number of Expansion Slots:
1
Total Number of Memory Slots:
4
Total Number of USB Ports:
6
